ES42 Series Edge Switches
Installation and User Guide (05/05)
Example 3: ES42P: In this example, the Magnum ES42P premium Edge Switches are
deployed to serve as a secure corporate or transportation surveillance system. CCTV
cameras may be spread out over many miles in temperature un-controlled locations and
with pan, tilt and zoom (PTZ) controlled through an Ethernet copper port .The premium
Edge Switches provide two fiber segments for secure long distance (2-40km)
communication while being installed in temperature un-controlled cabinets and allowing a
full range of AC and DC power options. The four copper ports at the remote location
provides access for other Ethernet equipment such as motion detectors or will act as a test
port for maintenance personnel with up-link for access to a central LAN and central file
servers.
34
