ES42 Series Edge Switches Installation and User Guide (05/05)
Media Edges may be placed on a tray, up to a maximum of 8 units. (The mounting spaces
of the MC14-TRAY are specific to the Magnum products and will not permit other models
to be properly mounted).
In a typical installation, the MC14-TRAY, 19” rack-mount tray will hold a few (three to
eight) ES42 Series Edge Switches, with their power supplies plugged into power strips (not
included) in the rear area of the tray. Metal mounting screws in the bottom-front hold the
Edge Switches firmly in place. The beveled-top edge of the units permits the LEDs of each
unit to be viewed for operational status, even when the units are very close together.
3.3 MC14-TR+PS9 and MC14-TR+PS9X2 for Rack Mounting Media Edges
The MC14-TR+ PS9 and MC14-TR+PS9X2 are other options for rack mounting the mix of
Magnum 10Mbps and 100Mbps Edge Switches and Media Edges together in a 19” rack-
mount tray. These models come with built-in common universal AC power supply rated at
55 watts at 50
°C ambient,9VDC output, and supporting up to 2-3 Switches for MC14-
TR+PS9 and 5 units ES42 Series for MC14-TR+PS9X2. The MC14-TR+PS9X2 Model
39
