8 308–532
SHUTDOWN, FLUSHING
AND STORAGE
WARNING
Pressure Relief Procedure
To reduce the risk of serious bodily injury
,
including fluid injection and splashing in the eyes,
or on the skin, always follow this procedure
whenever you stop spraying for more than 10
minutes, when shutting down, and before
checking or repairing any part of the system.
1. Engage the trigger safety latch.
2. Turn the sprayer off.
3. Remove the ignition cables from the spark
plugs.
4. Shut off the water supply.
5. Disengage the trigger safety latch and trigger
the gun to relieve pressure, and then engage
the trigger safety latch again.
6. Before long–term (overnight) storage or
transporting of the unit, disconnect the water
supply, and disconnect the fuel supply.
1. If the pressure washer will be exposed to freezing
temperatures, drain all water out of the pump. If it
must be stored in freezing temperatures, flush the
unit with a 50% anti–freeze solution. Relieve
pressure. Flush the pressure washer before using
it again to remove the anti–freeze.
NOTE: An anti–freeze flush kit, P/N 802–327, is
available to make flushing easier.
CAUTION
If water does freeze in the pressure washer, thaw
it in a warm room before trying to start it. DO NOT
pour hot water on or into the pump; it may crack
the ceramic plungers!
2. After each use, wipe all surfaces of the pressure
washer with a clean, damp cloth.
3. Perform the appropriate maintenance. See
maintenance chart.
MAINTENANCE
Observing regular maintenance intervals helps ensure
that you get maximum performance and life from the
pressure washer.
There is a break–in period for the engine and pump.
After changing the oil in these components following
their respective break–in periods, the interval between
required changes is longer.
If the unit is operating in dusty conditions, these
maintenance checks should be made more often.
WARNING
To reduce the risk of serious bodily injury ,
including fluid injection, splashing in the eyes or
on the skin or injury from moving parts, always
follow the Pressure Relief Procedure Warning
before proceeding.
Interval
Daily
After first 5
hours of
operation
Each 25 hours
of operation
After first 50
hours of
operation
Each 100 hours
of operation
or 3 months
Each 500 hours
of operation
or 6 months
What to do
Clean water inlet screen and
filter. Check engine and pump oil
levels. Fill as necessary. Check
gasoline level. Fill as necessary.
Change engine break–in oil.
Drain oil when warm. Use SAE
30 or 10W–30 detergent oil.
Clean and remove air cleaner
foam. Wash with water and
detergent. Dry thoroughly. Rub
with oil and squeeze to distribute
oil.
Change pump break–in oil. Use
SAE 20 or 30 non–detergent oil
or genuine CATr pump oil.
Clean or replace paper air
cleaner cartridge. Tap gently to
remove dirt. Change engine oil.
Use SAE 30 or 10W–30
detergent oil.
Change pump oil. Use SAE 20
or 30 non–detergent oil or
genuine CATr pump oil.
