15 308–532
PARTS LIST
Pump Assembly
REF PART
NO. NO. DESCRIPTION QTY
1 804–175 CRANKCASE 1
2 804–132 RING, Backup, valve cap 1
3 804–196 COVER, Crankshaft 1
4 801–028 O–RING, Oil Fill Cap 1
5 801–027 CAP, Oil Fill 1
6 804–190 O–RING, Crankcase Cover 1
7 804–158 COVER, Crankcase 1
8 804–171 GASKET, Sight Gauge 1
9 804–150 GAUGE, Sight, oil level 1
10 802–189 O–RING, Drain Plug 1
11 804–089 PLUG, Drain 1
12 804–238 SCREW, Cap, hex hd./cross
recess 6mm x 20mm 4
13 804–195 CRANKSHAFT 1
14 804–108 BEARING 2
15 804–109 SEAL, Oil, crankshaft 1
16 804–074 O–RING, Crankshaft Cover 2
17 804–114 SHIM 1
18 804–131 SEAL, Oil, crankshaft 1
19 804–237 SCREW, Cap, hex hd./cross
recess 6mm x 16mm 8
20 804–110 ROD, Connecting 3
21 804–160 ROD, Plunger 3
22 804–111 PIN, Rod 3
23 801–030 WASHER, Flat 3
24 801–031 SEAL, Oil, connecting rod 3
25 KIT C22 RETAINER, Seal, rear
26 804–121 WASHER, Flinger 3
27 804–161 WICK, Oil 3
28 801–036 PLUNGER, Ceramic 3
29 804–133 WASHER, Copper 3
30 804–235 STUD, 6mm x 58mm 3
31 801–038 RING, Backup 3
32 801–039 O–RING, Retaining, plunger 3
33 801–040 RETAINER, Plunger 3
34 802–753 PAN, Oil 1
35 804–199 MANIFOLD, Forged 1
36 KIT C22 ADAPTER, Front
37 KIT C22 PACKING, High Pressure
38 KIT C22 ADAPTER, Rear
39 804–211 CASE, Seal 3
40 KIT C22 PACKING, Low Pressure
REF PART
NO. NO. DESCRIPTION QTY
.
42 KIT C4 RING, Back Up
43 KIT C4 O–RING, Valve Seat
44 KIT C4 SEAT, Valve
45 KIT C4 VALVE
46 KIT C4 SPRING, Valve
47 KIT C4 RETAINER, Valve Spring
48 KIT C4 O–RING, Valve Cap
49 804–140 CAP, Valve 6
50 KIT C22 O–RING, Seal Case
51 804–075 WASHER, Flat, 6mm 12
52 KIT C22 RETAINER, Seal, front
53 804–077 WASHER, Lock, 6mm 12
54 804–233 SCREW, Cap, socket hd. ,
10mm x 25mm 4
55 804–214 WASHER, SST, 18mm 3
56 802–178 WASHER, Lock, 10mm 4
57 803–083 LABEL, Keep from freezing 1
58 804–247 PUMP 1
59 800–692 BRACKET, Pump 2
60 801–523 NIPPLE, 1/2 x 2 1
61 801–106 TEE, 1/2 1
62 800–113 FILTER (see instruction
manual 801–744) 1
63 801–111 NUT, Garden Hose 1
64 801–110 ADAPTER, Garden Hose 1
65 801–112 STRAINER, Garden Hose 1
66 100–214 WASHER, Lock 5/16 4
67 803–141 HOSE ASSEMBLY, Bypass 1
68 801–568 QUICK COUPLER, Male, 3/8 1
69 159–239 NIPPLE, Hex, 3/8 x 1/2 2
70 802–534 NIPPLE, Hex,
1/2 NPT x 1/2 NPSM 1
71 800–689 UNLOADER, 3500 PSI 1
800–427 UNLOADER, 4000 PSI 1
72 108–842 SCREW, Cap,
Hex hd. 8mm x 16mm 4
73 101–754 PLUG, 3/8 1
74 100–361 PLUG, 1/2 1
Kit
No.
Repair Kit
Part No.
Ref
No. Description Qty.
C4 801–041
Valve
42
43
44
45
46
47
48
RING, Back Up
O–RING, Valve
Seat
SEAT, Valve
VALVE
SPRING, Valve
RETAINER, Valve
Spring
O–RING, Valve
Cap
6
6
6
6
6
6
6
Kit
No.
Repair Kit
Part No.
Ref
No. Description Qty.
C22 804–099
Packing &
Retainer
25
36
37
38
40
50
52
RETAINER, Seal,
rear
ADAPTER, Front
PACKING, High
Pressure
ADAPTER, Rear
PACKING, Low
Pressure
O–RING, Seal
Case
RETAINER, Seal,
front
3
3
6
3
3
3
3
