Graco Inc. Hydra-Clean 800-706 - Manual (Page 25)

Kit
No.
Repair Kit
Part No.
Ref
No. Description Qty.
1 801–472
Valve
4
5
6
7
8
11
O–RING
SEAT, Valve
PLATE, Valve
SPRING
GUIDE, Valve
VALVE ASSEMBLY
6
6
6
6
6
6
2 801–473
Oil Seal
16 SEAL, Oil 3
3 802–511
Crankshaft Seal
41 SEAL, Oil 2
4 802–306
Valve Cap, 3000 psi
9
10
O–RING
CAP
6
6
6 801–474
Plunger Repair,
3000 psi
31
34
36
37
38
O–RING
WASHER, Flinger
RING, Backup
WASHER
SCREW, Piston
1
1
1
1
1
8 801–486
Packing, 3000 psi
44 PACKING 6
28 801–487
Packing & Retainer,
3000 psi
42
43
44
45
46
47
O–RING
RETAINER, Packing
PACKING
RING, Head
RETAINER, Packing
RING, Long Life
1
1
2
1
1
1
106 803–509
Valve Cap,
3500 & 4000 psi
9
10
O–RING
CAP
6
6
107 803–510
Plunger Repair,
3500 & 4000 psi
31
34
36
37
38
O–RING
WASHER, Flinger
RING, Backup
WASHER
SCREW, Piston
1
1
1
1
1
109 803–511
Packing, 4000 psi
44
47
–
PACKING
RING, Long life
PACKING
3
3
3
112 803–512
Packing &
Retainer,4000 psi
42
43
44
45
46
47
–
O-RING
RETAINER, packing
PACKING
RING, head
RETAINER, packing
RING, Long life
PACKING
1
1
1
2
1
1
1
1/30/95 3X8–532 Rev. D
