11 308–532
PARTS LIST
800–706 Hydra–Clean r 3540 Pressure Washer
REF PART
NO. NO. DESCRIPTION QTY
1 100–188 NUT, Hex 5/16–18 11
2 100–214 WASHER, Lock 5/16 13
3 801–285 BELT, Drive 2
4 804–136 SHEAVE, Engine 1
5 100–023 WASHER, Flat 5/16 27
6 801–941 SCREW, Cap, Hex hd
5/16–18 x 1 9
7 803–534 LABEL, Belt Guard 1
8 803–926 BELT GUARD 1
9 803–525 BOLT, Battery 2
10 804–282 BRACKET, Battery 1
11 801–972 PAD, Battery 1
12 801–550 WHEEL & TIRE ASSEMBLY 2
13 801–612 WASHER, Flat 1/2 2
14 801–020 NUT, Lock 1/2–13 2
15 800–676 CHASSIS 1
16 801–556 AXLE 1
17 800–678 BRACKET, Rail Stiffener 1
18 801–546 SCREW, Cap, Hex hd
3/8–16 x 1–1/4 4
19 100–133 WASHER, Lock 3/8 4
20 100–132 WASHER, Flat 3/8 4
21 800–160 FRONT LEG ASSEMBLY
(incl. 5, 78 through 84) 1
22 803–905 LABEL, Model 3540 1
23 111–040 NUT, Lock 5/16–18 4
24 803–925 HANDLE 1
25 803–298 SCREW, Cap, Hex hd
5/16–18 x 3–1/2 1
26 156–082 O–RING, Quick Coupler 3/8 2
27 154–594 O–RING, Quick Coupler 1/4 1
28 802–016 BRACKET, Rail Stiffener 1
29 801–522 SCREW, Cap, Hex hd 2
30 176–250 LABEL, Chassis 1
31 801–548 GROMMET, Rubber 5
32 172–981 LABEL, Chassis 1
33 800–314 TIP ASS’Y, 00045 (incl. 70, 71) 1
34 800–315 TIP ASS’Y, 15045 (incl. 70, 72) 1
35 800–316 TIP ASS’Y, 25045 (incl. 70, 73) 1
36 800–317 TIP ASS’Y, 40045 (incl. 70, 74) 1
37 803–883 ENGINE, 12.5 HP, Briggs &
Stratton Vanguard OHV 1
38 PUMP ASS’Y (see page 14) 1
39 800–652 FUEL TANK ASSEMBLY
(incl 40, 87, 89, 90, 91, 92)
40 802–026 BARB, Hose 1/4 1
41 801–571 HOSE, High Pressure 3/8 x 50’ 1
42 801–569 QUICK COUPLER, Female 3/8
(incl. 26) 2
43 801–568 QUICK COUPLER, Male 3/8 2
44 800–392 GUN & WAND ASSEMBLY
(incl. 42, 65, 66, 67, 68, 69) 1
REF PART
NO. NO. DESCRIPTION QTY
46 801–217 BUMPER, Rubber 1
47 177–144 LABEL, Belt Guard 1
48 803–535 SCREW, Cap, Hex hd 1
49 803–796 SHEAVE, Pump 1
50 801–898 HUB, Engine 1
51 801–135 HUB, Pump 1
52 801–959 TERMINAL PROTECTOR, Black1
53 801–945 CABLE, Battery 12” Long 1
54 803–077 LABEL, BATTERY 1
55 801–954 BATTERY, 12 Volt, 30 Amp 1
56 100–527 WASHER, Flat 1/4 2
57 100–016 WASHER, Lock 1/4 4
58 100–015 NUT, Hex 1/4–20 4
59 801–964 BOLT, Carriage 1/4–20 x 1 2
60 801–946 CABLE, Battery 24” Long 1
61 801–958 TERMINAL PROTECTOR, Red 1
62 803–531 BASEPLATE, Belt Guard 1
63 801–022 SCREW, Cap, Hex hd
5/16–18 x 3/4 4
64 107–069 BRACKET, Battery 1
65 801–009 QUICK COUPLER, Female 1/4
(incl. 27) 1
66 801–134 WAND, 32” 1
67 801–674 SLEEVE, 28” 1
68 803–350 GUN, Spray (see Instruction
Manual 308–511) 1
69 156–849 NIPPLE, Hex 3/8 1
70 801–090 QUICK COUPLER, Male 1/4 4
71 803–106 TIP, Spray 00045 1
72 803–107 TIP, Spray 15045 1
73 803–108 TIP, Spray 25045 1
74 803–109 TIP, Spray 40045 1
75 800–375 HOSE ASSEMBLY W/QUICK
COUPLERS (incl 41, 42, 43) 1
76 802–363 LABEL, Caution 1
77 181–867 LABEL, Warning 1
78 801–531 SCREW, Cap, Hex hd
3/8–16 x 7 1
79 801–504 BUMPER, Rubber 1
80 801–505 RETAINER, Spring 1
81 801–593 SPRING 1
82 801–506 BOOT 1
83 801–537 LEG, Front 1
84 801–499 NUT, Lock 3/8–16 1
85 802–907 CONNECTOR, Fuel 1
86 801–919 BRACKET, Fuel Connector 1
87 801–971 CLAMP, Hose 3
88 801–629 LINE, Fuel 1
89 801–716 LABEL, Warning 2
90 803–881 LINE, Fuel w/Squeeze Bulb 1
91 802–025 TANK, Fuel 1
92 801–008 LABEL, Graco G 1
