Goodman Mfg GPH13M - Manual (Page 4)

P
roduct
S
PecificationS
P
roduct
S
PecificationS
4 www.goodmanmfg.com SS-GPH13M
S
pecificationS
(
cont
.)
GPH13
42M41A*
GPH13
42M41C*
GPH13
48M41A*
GPH13
48M41C*
GPH13
60M41A*
GPH13
60M41C*
Cooling Capacity
Total BTU/h 40,000 41,000 46,500 47,000 56,000 56,000
Sensible BTU/h 29,200 31,000 36,800 37,600 40,800 42,000
SEER / EER 13/11 13/11 13/11 13/11 13/10.9 13/10.9
Decibels 80.1 80.1 79.1 79.1 80.2 80.2
AHRI #s 4385124 5696970 4385126 5696971 4385129 5696972
Heating Capacity
BUT/h (47°F)
40,000 41,000 45,500 47,000 55,500 55,500
C.O.P (47°F) 3.5 3.6 3.7 3.7 3.6 3.6
BUT/h (17°F) 21,000 23,000 26,000 27,000 31,200 31,200
C.O.P (17°F) 2.18 2.2 2.3 2.3 2.24 2.24
HSPF 7.7 7.7 8.0 8.0 8.0 8.0
Evaporator Motor
Type DD DD X-13 X-13 X-13 X-13
Wheel (DxW) 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9 10 x 9
Nominal Cooling CFM 1,300 1,385 1,720 1,690 1,800 1,775
FLA/LRA 3.06 / 4.1 3.06 / 4.1 5.8 / -- 5.8 / -- 7.6 / -- 7.6 / --
No. of Speeds 3 3 5 5 5 5
Horsepower - RPM ⅓ - 910 ⅓ - 910 ¾ - 1,050 ¾ - 1,050 1 - 1,050 1 - 1,050
Evaporator Coil
Face Area (ft²)
4.52 4.55 6.17 6.20 6.17 6.20
Rows Deep/ Fin per Inch 4 / 14 4 / 14 4 / 14 4 / 14 4 / 14 4 / 14
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"
Refrigerant Charge (oz.) 180 180 190 200 220 220
Condenser Fan / Coil
Horsepower - RPM
¼ - 1,075 ¼ - 1,075 ¼ - 1,075 ¼ - 1,075 ¼ - 1,075 ¼ - 1,075
FLA/LRA 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9
Fan Diameter / # Fan Blades 22/3 22/3 22/3 22/3 22/3 22/3
Face Area (ft²) 16.83 16.83 19.24 19.24 21.04 21.04
Rows Deep/ Fin per Inch 2 / 16 2 / 16 2 / 16 2 / 16 2 / 16 2 / 16
Compressor
Quantity
1 1 1 1 1 1
Type Scroll Scroll Scroll Scroll Scroll Scroll
Stage Single Single Single Single Single Single
Electrical Data
Voltage/ Phase/ Frequency
208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60
Compressor RLA/ LRA 17.9 / 112 17.9 / 112 21.8 / 117 21.8 / 117 26.4 / 134 26.4 / 134
Total Unit Amps 22.36 22.4 29 29 35.4 35.4
Min. Circuit Ampacity¹ 26.8 26.8 34.5 34.5 42.0 42.0
Max. Overcurrent Protection² 40 amps 40 amps 50 amps 50 amps 60 amps 60 amps
Shipping Weight (lbs) 440 440 520 485 533 495
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
