HYDRAULIC AND HANDLE ASSEMBLY
Hydraulc and Handle Assembly - 49
PART NO
QTY
DESCRIPTION
D13028
2
SWIVEL ADJUSTER
D13308
1
BASE, LOCK LEVER Y
D13309
1
LEVER, LOCK Y
D18023
1
DECAL, HYDRO OIL SPECS.
D18079
1
GRIP, PVC .250 X 1.00 X 3.63
D18093
2
GRIP, CONTROL
D24020
3
SCREW, 8-32X .50 PAN PHL Y
D24028
1
FTG, 90 9/16 MOR X 3/8 HOSE
GDA10066
1
ELBOW, FITTING
GDA10137
1
FILTER, OIL
M117554
1
DECAL, WARNING - HOT SURFACES
M63431
3
NUT, 8-32 ELASTIC STOP
TCA15122
1
CAP, FILLER OIL
TCA15195
1
WLDT, PIVOT ROD Y
TCA15373
1
WLDT, RESERVIOR HYDRAULIC
TCU15907
1
DECAL, WARNING, SLOPE
TCU15910
1
DECAL, DIRECTIONAL CONTROL
102770
3
RELAY, ISO MINI ELEC.
111910
3
CABLE TIE, .15 X 8.50
121080
3
PIN, HAR .091 X 1.63 5/16-1/2 Y
180640
1
SOLENOID, 12 V STARTER
180842
1
CABLE, 12" STARTER
200037
1
DECAL, PATENT COVERED
200116
4
BRG, FLG .500X.620X.500 BRNZ
200606
1
PAD, THIGH
200615
1
LINK. BRAKE Y
200743
1
CONTROL PANEL S/O
200654
1
HANDLE, SUPPORT
200671
1
BUSHING, BRAKE PIVOT Y
200690
1
WLDT, THIGH PAD BRACKET
200705
1
SWITCH, NO-NO-NC GREY PLUNGER
201022
1
BRAKE LEVER, OFFSET
201354
1
WLDT, CONSOLE 34
201358
1
WLDT, RH CONTROL LEVER
201359
1
WLDT, LH CONTROL LEVER
201197
1
HARNESS, WIRING
313270
1
FTG, 90 9/16 MOR X 9/16 MJIC
34H60
1
PIN, SPRING
960000
2
BOLT, 1/4-20 X .500 HEX 5 Y
960001
7
BOLT, 1/4-20 X .750 HEX 5 Y
960002
2
BOLT, 1/4-20 X 1.00 HEX 5 Y
960046
2
BOLT, 3/8-16 X 1.00 HEX 5 Y
960500
2
NUT, 1/4-20 STD HEX GR5 Y
960600
6
WASHER, .250 MED SPRG LOCK Y
960702
4
WASHER, .375 REG FLAT Y
963020
4
BOLT, 3/8-16 X 1.00 CRG 5 Y
963053
1
BOLT, 3/8-16 X 1.25 CRG 5 Y
964048
3
LOCKNUT, 1/4-20 NYLOC Y
968087
6
LOCKNUT, 3/8-16 NYLOC Y
