SERVICE ENGINE
SERVICE ENGINE- 19
Service Lubrication
Grease
IMPORTANT: Avoid Damage! The recommended grease is
effective within an average air temperature range of -29 to
135 degrees C (-20 to 275 degrees F).
IMPORTANT: Avoid Damage! Use only NLGI No. 2 lithium
based grease.
• If operating outside that temperature range, contact your
servicing dealer for a special-use grease.
Use a general all-purpose grease with an NLGI grade No.2
rating.
Wet or high speed conditions may require use of a special-
use grease. Contact your Servicing dealer for information.
Lubricating Front Caster Spindles and Wheels
CAUTION: Avoid injury! Fingers or loose
clothing can get caught in rotating parts. Stop
engine and wait for all moving parts to stop
before servicing.
A
B
• Lubricate two spindle grease fittings (A) and two wheel
grease fittings (B).
Lubricating Pump Idler Pivot
A
Lubricate one pump idler pivot grease fitting (A). Lubri-
cate either the fitting on the top of the engine bed or the
one under the pump shield.
Lubricating Mower Deck Spindles
A
B
• Lubricate three mower deck spindle grease fittings (A).
Lubricating Mower Deck Idler Pivot
• Lubricate one deck idler pivot grease fitting (B).
•
