Selection Charts
310692D 5
Gravity feed spray guns (without gravity cup)
Gravity feed spray guns with 16 oz. gravity cup
Gravity feed spray guns with 3M
™
PPS
™
gravity cup
Orifice size
in. (mm) HVLP Compliant Airspray
.055 (1.4) 234658 234685 234662
.070 (1.8) 234659 234686 234663
Orifice size
in. (mm) HVLP Compliant Airspray
.055 (1.4) 234713 234721 234705
.070 (1.8) 234714 234722 234706
Orifice Size
in. (mm) HVLP Compliant Airspray
.055 (1.4) 234681 234689 234677
.070 (1.8) 234682 234690 234678
