2-3
Integrated Peripherals
On-Chip Primary PCI IDE
Enabled
Enable onboard 1st channel IDE port. (Default value)
Disabled
Disable onboard 1st channel IDE port.
On-Chip Secondary PCI IDE
Enabled
Enable onboard 2nd channel IDE port. (Default value)
Disabled
Disable onboard 2nd channel IDE port.
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Integrated Peripherals
KLJI: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Save Default
F7: Optimized Defaults
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Integrated Peripherals
On-Chip Primary PCI IDE
[Enabled]
On-Chip Secondary PCI IDE
[Enabled]
On-Chip SATA
[Auto]
x SATA Port0 Configure as
SATA Port0
SATA Port1 Configure as
SATA Port1
USB Controller
[Enabled]
USB 2.0 Controller
[Enabled]
USB Keyboard Support
[Disabled]
USB Mouse Support
[Disabled]
AC97 Audio
[Auto]
Onboard H/W LAN
(
*
)
[Enabled]
Onboard LAN Boot ROM
(
*
)
[Disabled]
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Serial Port 2
[2F8/IRQ3]
UART Mode Select
[Normal]
x UR2 Duplex Mode
Half
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x ECP Mode Use DMA
3
KLJI: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Save Default
F7: Optimized Defaults
Game Port Address
[201]
Midi Port Address
[Disabled]
Midi Port IRQ
10
CIR Port Address
[Disabled]
x CIR Port IRQ
11
Item Help
Menu Level`
Item Help
Menu Level`
If a hard disk
controller card is
used, set at Disabled
[Enabled]
Enable on-chip IDE
Port
[Disabled]
Disable on-chip IDE
Port
(*) Only for GA-8IP775-G.
