GA-8IP775 Series Motherboard - 10 -
English
Motherboard w GA-8IP775 Series Motherboard:
GA-8IP775-G/GA-8IP775
CPU w Supports the latest Intel ® Pentium ® 4 LGA775 CPU
w Supports 800/533MHz FSB
w L2 cache varies with CPU
Chipset w Northbridge: Intel ® 865P
w Southbridge: Intel ® ICH5
Memory w 4 DDR DIMM memory slots (supports up to 4GB memory) (Note 1)
w Supports dual channel DDR 400 (Note 2) /333/266 DIMM
w Supports 2.5V DDR DIMM
Slots w 1 AGP slot
w 5 PCI slots
IDE Connections w 2 IDE connection (UDMA 33/ATA 66/ATA 100), allows connection of 4
IDE devices
FDD Connections w 1 FDD connection, allows connection of 2 FDD devices
Onboard SATA w 2 Serial ATA connections
Peripherals w 1 parallel port supporting Normal/EPP/ECP mode
w 2 Serial port (COMA/COMB)
w 8 USB 2.0/1.1 ports (rear x 4, front x 4 via cable)
w 1 front audio connector
w 1 IR/CIR connector
w 1 PS/2 keyboard port
w 1 PS/2 mouse port
Onboard LAN ( * ) w Onboard Marvell 8001 chip (10/100/1000 Mbit)
w 1 RJ 45 port
Onboard Audio w ALC850 CODEC (UAJ)
w Supports Jack Sensing function
w Supports 2 / 4 / 6 / 8 channel audio
w Supports Line In / Line Out / MIC connection
w Surround Back Speaker (use of Surround-Kit to select)
w SPDIF In / Out
w CD In / Gam e connector
(Note 1) Due to standard PC architecture, a certain amount of memory is reserved for system usage and
therefore the actual memory size is less than the stated amount.
For example, 4 GB of memory size will instead be shown as 3.xxGB memory during system startup.
(Note 2) When FSB800 is selected as CPU frequency, memory will automatically adjust to DDR400.
1-2 Feature Summary
Due to chipset (Intel 865P) architecture limitation, a FSB 800 Pentium 4 processor will support
DDR400 memory module. A FSB 533 Pentium 4 processor will support DDR333 and DDR266
memory module.
(*) Only for GA-8IP775-G.
