Step 6: configuration report, Step 6: configuration report –11 – GE P485 User Manual
Page 67
APPLICATION EXAMPLE
P485 MODBUS TO PROFIBUS CONVERTER – USER GUIDE
9–11
5.
Click Next to proceed to the final step of the configuration wizard
STEP 6: CONFIGURATION
REPORT
The final step in the wizard provides a configuration report for the device.
1.
If desired, click on Print to print the configuration report.
Figure 9-17: Configuration report
2.
For future reference, saved the file in RTF format by clicking the Save as RTF button
and selecting an appropriate directory.
3.
Click the Sub-net Oveview button to view the data mapping.
Figure 9-18: Modbus network monitor
4.
Close the Modbus network monitor window.
5.
Click on Next to complete the configuration wizard.
Figure 9-19: Wizard finished
