8 www.goodmanmfg.com SS-CPG36-72 SS-CPG36-72 www.goodmanmfg.com 9
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
rodUCt
s
PeCiFiCations
— CPG060 (
Cont
.)
CPG060
1403B***B
CPG060
1403B***C*
CPG060
1404B***B
CPG060
1404B***C*
CPG060
1407B***B
CPG060
1407B***C*
Cooling Capacity
Total BTU/h
59,500 58,000 59,500 58,000 58,500 58,000
Sensible BTU/h 43,200 43,200 43,200 43,200 42,500 42,500
SEER / EER 13 / 11.0 13 / 11.1 13 / 11.0 13 / 11.1 13 / 11.0 13 / 11.1
Decibels 78 78 78 78 78 78
AHRI Reference #s 4385066 5368226 4385067 5368227 4397609 5368228
Gas Heating Capacity
High Input /Output kBTU/h
138 / 110.4 138 / 110.4 138 / 110.4 138 / 110.4 138 / 110.4 138 / 110.4
Low Input /Output kBTU/h 103 / 83 103 / 83 103 / 83 103 / 83 103 / 83 103 / 83
Steady State Efficiency (AFUE) 80 80 80 80 80 80
Temperature Rise Range (°F) 35-65 / 25-55 35-65 / 25-55 35-65 / 25-55 35-65 / 25-55 35-65 / 25-55 35-65 / 25-55
No. of Burners 6 6 6 6 6 6
Evaporator Motor / Coil
Motor Type
Belt Belt Belt Belt Belt Belt
Indoor Nominal CFM 1,900 1,900 1,900 1,900 1,900 1,900
Piston Size (Cooling) 0.086 0.086 0.086 0.086 0.086 0.086
Filter Size (#) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4) 14 x 20 x 2 (4)
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 165 100.8 165 100.8 165 100.8
Face Area (ft²) 7.8 7.8 7.8 7.8 7.8 7.8
Rows Deep/ Fins per Inch 4 / 16 4 / 16 4 / 16 4 / 16 4 / 16 4 / 16
Tube Diameter - Material 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper 5/16 - Copper
Belt Drive Evap Fan Data
# of Wheels (D x W)
1 (11" x 10") 1 (11" x 10") 1 (11" x 10") 1 (11" x 10") 1 (11" x 10") 1 (11" x 10")
Motor Sheave / Blower Sheave VL44 X ⅝ / AK61 X 1 VL44 X ⅝ / AK61 X 1 VL44 X ⅝ / AK61 X 1 VL44 X ⅝ / AK61 X 1 VL44 X ⅝ / AK61 X 1 VL44 X ⅝ / AK61 X 1
Belt AX53 AX53 AX53 AX53 AX53 AX53
Condenser Fan / Coil
Horsepower / RPM
¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ / 1,075 ¼ / 1,075
Fan Diameter/ # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 1 22 / 1
Outdoor Nominal CFM 3,800 3,800 3,800 3,800 3,800 3,800
Face Area (ft²) 17.0 13.0 17.0 13.0 17.0 13.0
Rows Deep/ Fins per Inch 2 / 18 2 / 27 2 / 18 2 / 27 2 / 18 2 / 27
Tube Diameter - Material 5/16 - Copper 5MM - Copper 5/16 - Copper 5MM - Copper 5/16 - Copper 5MM - Copper
Compressor
Quantity / Stage / Type
1 / Single / Scroll 1 / Single / Scroll 1 / Single / Scroll 1 / Single / Scroll 1 / Single / Scroll 1 / Single / Scroll
Compressor RLA / LRA 16 / 110 16 / 110 7.8 / 52 7.8 / 52 5.7 / 38.9 5.7 / 38.9
Electrical Data
Voltage-Phase-Frequency
208/230-3-60 208/230-3-60 460-3-60 460-3-60 575-3-60 575-3-60
Indoor Blower HP / FLA (STD Static) 1.0 / 3.8 1.0 / 3.8 1.0 / 1.9 1.0 / 1.9 1.5 / 2.3 1.5 / 2.3
Belt-Drive High Static FLA 1.5 / 5.0 1.5 / 5.0 1.5 / 2.5 1.5 / 2.5 1.5 / 2.5 1.5 / 2.5
Indoor Blower LRA 24 24 13 13 12 12
Max External Static 1.0 1.0 1.0 1.0 1.0 1.0
Outdoor Fan HP / FLA ¼ / 1.40 ¼ / 1.40 ¼ / 0.8 ¼ / 0.8 ¼ / 0.6 ¼ / 0.6
Min. Circuit Ampacity¹ 25 25 12 12 10 10
Max. Overcurrent Protection ² 40 amps 40 amps 20 amps 20 amps 15 amps 15 amps
Power Supply Conduit Hole 1.125 1.125 1.125 1.125 1.125 1.125
Low-Voltage Conduit Hole ½" ½" ½" ½" ½" ½"
Operating/Shipping Weight (lbs) 630/ 655 620/ 645 630/ 655 620/ 645 630/ 655 620/ 645
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
