2 www.goodmanmfg.com SS-CPG36-72 SS-CPG36-72 www.goodmanmfg.com 3
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
rodUCt
s
PeCiFiCations
— CPG036
CPG036
0451D***B*
CPG036
0453D***B*
CPG036
0453B***B*
CPG036
0454B***B*
Cooling Capacity
Total BTU/h
34,600 34,600 34,600 34,600
Sensible BTU/h 25,600 25,600 25,600 25,600
SEER / EER 13 / 11.0 13 / 11.0 13 / 11.0 13 / 11.0
Decibels 78 78 78 78
AHRI Reference #s 4385059 4385060 4385060 4385061
Heating Capacity
High Input / Output kBTU/h
46 / 36.8 46 / 36.8 46 / 36.8 46 / 36.8
Steady State Efficiency (AFUE) 80 80 80 80
Temperature Rise Range (°F) 25-55 25-55 25-55 25-55
No. of Burners 2 2 2 2
Evaporator Motor / Coil
Motor Type
Direct Drive Direct Drive Belt Drive Belt Drive
# of Wheels (D x W) 1 (10” x 9”) 1 (10” x 9”) 1 (11” x 10”) 1 (11” x 10”)
Indoor Nominal CFM 1,200 1,200 1,200 1,200
Motor Speed Tap (Cooling) Low Speed Low Speed --- ---
Indoor Motor FLA (Cooling) 2.50 2.50 3.8 1.9
Horsepower - RPM ⅓ - 890 ⅓ - 890 1.0 - 1725 1.0 - 1725
Piston Size (Cooling) 0.072 0.072 0.072 0.072
Filter Size (“) (1) 24 x 24 x 2 (1) 24 x 24 x 2 (1) 24 x 24 x 2 (1) 24 x 24 x 2
Drain Size (NPT) ¾” ¾” ¾” ¾”
R-410A Refrigerant Charge Cir #1(oz.) 83 83 83 83
Evaporator Coil Face Area (ft²) 5.4 5.4 5.4 5.4
Rows Deep/ Fins per Inch 3/16 3/16 3/16 3/16
Belt Drive Evap Fan Data
# of Wheels (D x W)
--- --- 1 (11” x 10”) 1 (11” x 10”)
Motor Sheave / Blower Sheave --- --- 1VL40 X ⅝ / AK69 X 1 1VL40 X ⅝ / AK69 X 1
Belt --- --- AX52 AX52
Condenser Fan / Coil
Quantity of Condenser Fan Motors
1 1 1 1
Horsepower - RPM ¼ / 1,090 ¼ / 1,090 ¼ / 1,090 ¼ - 890
Fan Diameter/ # Fan Blades 22/4 22/4 22/4 22/4
Outdoor Nominal CFM 3,800 3,800 3,800 3,800
Face Area (ft²) 17.0 17.0 17.0 17.0
Rows Deep/ Fins per Inch 1 / 24 1 / 24 1 / 24 1 / 24
Compressor
Quantity / Stage
1 / Single 1 / Single 1 / Single 1 / Single
Type Scroll Scroll Scroll Scroll
Compressor RLA / LRA 16.7 / 79.0 10.4 / 73.0 10.4 / 73.0 5.8 / 38.0
Electrical Data
Voltage-Phase-Frequency
208/230-1-60 208/230-3-60 208/230-3-60 460-3-60
Indoor Blower HP / FLA ⅓ / 2.5 ⅓ / 2.5 1 / 3.8 1 / 1.9
Outdoor Fan HP / FLA ¼ / 1.4 ¼ / 1.4 ¼ / 1.4 ¼ / 0.8
Total Unit Amps 20.57 14.35 15.65 8.47
Min. Circuit Ampacity¹ 25 17 18 10
Max. Overcurrent Protection (amps)² 40 25 25 15
Power Supply Conduit Hole / Knockout 1.125 1.125 1.125 1.125
Low-Voltage Conduit Hole ½” ½” ½” ½”
Operating Weight (lbs) 525 525 525 525
Ship Weight (lbs) 550 550 550 550
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
