10 www.goodmanmfg.com SS-CPG36-72 SS-CPG36-72 www.goodmanmfg.com 11
P
roduct
S
PecificationS
P
roduct
S
PecificationS
P
rodUCt
s
PeCiFiCations
— CPG072
CPG072
1403B***B*
CPG072
1403B***C*
CPG072
1404B***B*
CPG072
1404B***C*
CPG072
1407B***B*
CPG072
1407B***C*
Cooling Capacity
Total BTU/h
71,000 71,000 71,000 71,000 71,000 71,000
Sensible BTU/h 48,280 49,800 48,280 49,800 48,280 49,800
EER / IEER 11.1 / 11.2 11.0 / 11.2 11.1 / 11.2 11.0 / 11.2 11.1 / 11.2 11.0 / 11.2
Decibels 78 78 78 78 78 78
AHRI Number 5104774 5582882 5104774 5582882 5104774 5582882
Heating Capacity
High Input / Output KBTU/h
138 / 110.4 138 / 110.4 138 / 110.4 138 / 110.4 138 / 110.4 138 / 110.4
Low Input/ Output KBTU/h 103 / 83 103 / 83 103 / 83 103 / 83 103 / 83 103 / 83
Steady State Efficiency 80 80 80 80 80 80
Temperature Rise Range (°F) 30-60 / 15-45 30-60 / 15-45 30-60 / 15-45 30-60 / 15-45 30-60 / 15-45 30-60 / 15-45
No. of Burners 6 6 6 6 6 6
Evaporator Motor / Coil
Motor Type
Belt Drive Belt Drive Belt Drive Belt Drive Belt Drive Belt Drive
# of Wheels (D x W) 1 (11" x 10") 1 (11" x 10") 1 (11" x 10") 1 (11" x 10") 1 (11" x 10") 1 (11" x 10")
Indoor Nominal CFM 2,350 2,350 2,350 2,350 2,350 2,350
Indoor Motor FLA (Cooling) 5.0 5.0 2.5 2.5 2.3 2.3
Horsepower - RPM 1.5-1,725 1.5-1,725 1.5-1,725 1.5-1,725 1.5-1,725 1.5-1,725
Piston Size (Cooling) 0.094 0.094 0.094 0.094 0.094 0.094
Filter Size (Qty) (4) 16" x 20" x 2" (4) 16" x 20" x 2" (4) 16" x 20" x 2" (4) 16" x 20" x 2" (4) 16" x 20" x 2" (4) 16" x 20" x 2"
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 213.0 146.0 213.0 146.0 213.0 146.0
Evaporator Coil Face Area (ft²) 8.9 8.9 8.9 8.9 8.9 8.9
Rows Deep/ Fins per Inch 4/ 16 4/ 16 4/ 16 4/ 16 4/ 16 4/ 16
Motor Sheave VL44 X 7/8 VL44 X 7/8 VL44 X 7/8 VL44 X 7/8 VL44 X 7/8 VL44 X 7/8
Blower Sheave AK59 X 1 AK59 X 1 AK59 X 1 AK59 X 1 AK59 X 1 AK59 X 1
Belt AX53 AX53 AX53 AX53 AX53 AX53
Condenser Fan / Coil
Quantity of Condenser Fan Motors
1 1 1 1 1 1
Horsepower - RPM ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075 ⅓ - 1,075
Fan Diameter/ # Fan Blades 22/ 4 22/ 4 22/ 4 22/ 4 22/ 4 22/ 4
Outdoor Nominal CFM 4,200 4,200 4,200 4,200 4,200 4,200
Face Area (ft²) 18.7 19 18.7 19 18.7 19
Rows Deep/ Fins per Inch 2/ 20 2/ 27 2/ 20 2/ 27 2/ 20 2/ 27
Compressor
Quantity / Stage/ Type
1/ Single/ Scroll 1/ Single/ Scroll 1/ Single/ Scroll 1/ Single/ Scroll 1/ Single/ Scroll 1/ Single/ Scroll
Compressor RLA / LRA 19/ 123 19/ 123 9.7/ 62 9.7/ 62 7.4/ 50 7.4/ 50
Electrical Data
Voltage/ Phase/ Frequency
208-230/ 3/ 60 208-230/ 3/ 60 460/ 3/ 60 460/ 3/ 60 575/ 3/ 60 575/ 3/ 60
Belt-Driven Standard Max Static 1.0 1.0 1.0 1.0 1.0 1.0
Outdoor Fan FLA 1.90 1.90 1.20 1.20 0.90 0.90
Total Unit Amps 25.9 25.9 13.4 13.4 10.6 10.6
Min. Circuit Ampacity¹ 31 31 16 16 12 12
Max. Overcurrent Protection² 45 amps 45 amps 25 amps 25 amps 15 amps 15 amps
Entrance Power Supply 1.125" 1.125" 1.125" 1.125" 1.125" 1.125"
Entrance Control Voltage ½" ½" ½" ½" ½" ½"
Operating/Shipping Weight (lbs) 690/ 715 675/ 700 690/ 715 675/ 700 690/ 715 675/ 700
¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• When a factory-installed powered convenience outlet is installed in the equipment, the unit MCA (Min. Circuit Ampacity) will increase by 7.5A for
208/230V units, increase by 3.75A for 460V units, and by 3A for 575V units. The MOP (Max. Overcurrent Protection) device must be sized accordingly.
