Great Dane Super Surfer Series II GSKH2561S User Manual
Page 75

Mower Deck Spindles - 73
MOWER DECK SPINDLES
NOTES
Ref. No.
Part No.
Description
Qty.
Remarks
1
200262
Spindle Assembly
1
Includes items 2, 3, 4, 5, 6, 14
2
200046
Ball Bearing
2
3
200042
Housing
1
4
200044
Spacer
1
1.000 x 1.250 x 2.772
5
200196
Shaft, Spindle
1
6
200045
Bolt
6
3/8-16 x 1.25 Rib
7
967333
Nut, Pulley
3
3/4-16 Flange
8
D18209
Pulley, Cutter Housing, 48" Deck
3
D18084
Pulley, Cutter Housing, 52" Deck
3
D18211
Pulley, Cutter Housing, 61" Deck
3
9
D13024
Spacer, Pulley
3
10
967348
Bolt, Blade
3
5/8-11 x 2 Grade 8
11
960502
Nut
18
3/8-16 Std Hex Gr5
12
D18055
Spacer, Blade Bolt
9
13
GDU10230
16.5" Blade, 48" Deck
3
GDU10231
18.0" Blade, 52" Deck
3
GDU10232
21.0" Blade, 61" Deck
3
14
959995
Zerk, Grease S/O
1
