Drive Controls and Linkage - 47
DRIVE CONTROLS AND LINKAGE
* Included with new Hydrostatic Pump.
NOTES
Ref. No. Part No. Description Qty. Remarks
1 D18069 Speed Limiter 1
2 200080 Steering Controller, RH 1
200081 Steering Controller, LH 1
3 D13029 Control Rod 2
4 14M7303 Flange Nut 2 M6 x 1.0
5 J16913 Spring Pin 2
6 D13028 Swivel 2
7 D38157 Rod End 2
8 D18093 Grip 2
9 19M7547 Cap Screw, Reverse Stop 2 M6 x 1.0 x 55
10 14M7400 Flange Lock Nut 3 M10 x 1.5
11 D13308 Base, Speed Control Lock 1
12 D13309 Handle 1
13 34H60 Spring Pin 1 5/32 x 1
14 TCA15195 Shaft, Pivot 1
15 19M7862 Cap Screw 1 M6 x 1.0 x 20
16 14M7397 Lock Nut 1 M6 x 1.0
17 19M7785 Cap Screw 3 M10 x 1.5 x 25
18 191256 Switch, Neutral 2
19 19H1905 Cap Screw 2 5/16-18 x 1
20 200116 Bushing 4
21 14H650 Jam Nut 2 5/16-24
22 19M7372 Cap Screw 2 M5 x 0.8 x 16
23 14M7360 Nut 2 M5 x 0.8
24 D14081 Lock Nut 2 5/16-18
25* TCU19201 Arm, Control RTN 2
26* TCU19202 Arm, Return 2
27* TCU18929 Arm, RH Inner RTN 2
TCU18931 Arm, LH Inner RTN 2
28* TCU18932 Arm, LH Outer RTN 2
TCU18930 Arm, RH Outer RTN 2
29* TCU19203 Spacer 2
30* TCU19204 Spring 2
31* TCU19209 Screw 2 5/16 x 1 patch lock
32* TCU19205 Washer 4
33* TCU19206 Washer, Nylon 4
34* TCU19207 Lock Nut 2 5/16-24
35* TCU19208 Spacer 2
36 24H1305 Washer 1 .406 x .812 x .065 Flat
