KOHLER Engine and Related Components - 59
KOHLER ENGINE AND RELATED COMPONENTS
* NOTE: See authorized KOHLER servicing engine dealer for engines and engine related service items. Always
reference the engine model number when ordering parts.
NOTES
Ref. No.
Part No.
Description
Qty.
Remarks
1
D28121
Muffler
1
2
*
Gasket
1
3
TCA15389
Oil Drain Hose
1
4
X6PMTX-S
Oil Drain Plug
1
5
03M7188
Carriage Bolt, Engine Mounting
1
M8 x 1.25 x 40
6
19M8317
Cap Screw, Engine Mounting
3
M8 x 1.25 x 40
7
14M7396
Flange Lock Nut, Engine Mounting
4
M8 x 1.25
8
14M7298
Flange Nut, Muffler
4
M8 x 1.25
9
D18427
Cable, Choke
1
10
D18359
Cable, Throttle
1
11
D24020
Bolt, Throttle Cable
2
0.164" x 1/2"
12
M63431
Lock Nut, Throttle Cable
2
0.164"
13
14H846
Nut, Choke Cable
1
3/8"
14
12M7032
Washer
1
