Great Dane Super Surfer Series II GSKH2561S - Manual (Page 47)

Main Frame, Traction Deck, Console and OPC Platform - 45
MAIN FRAME, TRACTION DECK, CONSOLE AND OPC PLATFORM
Ref. No. Part No. Description Qty. Remarks
1 TCA14936 Frame - 1 W/ 48"-52" Deck
TCA14946 Frame - 1 W/ 61" Deck
2 D15356 Fender, Left 1
D15355 Fender, Right 1
3 200038 Weight 2
4 19M7270 Cap Screw 6 M8 x 1.25 x 65
5 19M7803 Cap Screw 6 M8 x 1.25 x 70
6 14M7396 Nut 12 M8 x 1.25
7 JD7842 Lubrication Fitting 4
8 200218 Deck Shield Assembly 1 48" and 52" deck
TCA15350 Deck Shield Assembly 1 61" deck
9 M119352 Knob 2
10 14M7299 Nut 6 M12 x 1.75
11 TCA14912 Control Console 1
12 TCA14919 Side Bracket, Left 1
13 TCA14918 Side Bracket, Right 1
14 TCA15348 Handle Mount 1
15 D15368 Plate, Thigh Pad 1
16 TCA15060 Pad, Thigh 1
17 TCA15371 Shield 1
18 D15305 Plate 1
19 TCA14856 Engine/Traction Deck 1
20 03M7191 Carriage Bolt 6 M10 x 1.5 x 25
21 14M7400 Flange Nut, Locking 6 M10 x 1.5
22 19H1948 Cap Screw 4 1/4" x 3/4"
23 12H302 Lock Washer 4 1/4"
24 19M7784 Cap Screw, Flange Head 6 M10 x 1.5 x 20
25 19M7785 Cap Screw 4 M10 x 1.5 x 25
26 14M7400 Flange Nut, Locking 4 M10 x 1.5
27 19M7784 Cap Screw, Flange Head 4 M10 x 1.5 x 20
28 T34037 Cap Screw 4 3/8"-16 x 3/4"
29 19M7784 Cap Screw, Flange Head 2 M10 x 1.5 x 20
30 14M7400 Flange Nut, Locking 2 M10 x 1.5
31 19M7784 Cap Screw, Flange Head 6 M10 x 1.5 x 20
32 M115279 Plug 1 Optional light switch hole
