Caster Wheels and Rear Wheels - 67
CASTER WHEELS AND REAR WHEELS
NOTES
Ref. No. Part No. Description Qty. Remarks
1 TCU17863 Spacer, Caster Bushing 2
2 E14625 Seal 2
3 D38035 Bearing Assembly, Caster Wheel 4 Cup and cone
4 D28051 Bearing Assembly, Caster Yoke 4 Cup and cone
5 11M7083 Cotter Pin 2
6 A12188 Castle Nut 2 1"-14
7 M135582 Cap, Bearing 2
8 JD7844 Grease Fitting 2
9 D25004 Yoke 2
10 D33007 Spacer, Caster Wheel 4
11 D28097 Cap Screw 2 3/4"-16 x 8"
12 D24008 Nut 2 3/4"-16
13 D38009 Caster Wheel and Tire Assembly 2 Includes items 3 and 17
14 TCA15086 Caster Arm 2
15 19M7785 Cap Screw 12 M10 x 1.5 x 25
16 14M7518 Nut 12 M10 x 1.5
17 D38065 Seal 4
18 TCA15147 Wheel and Tire Assembly, Rear 2 48" deck, 20 x 8-8 tire
TCA15148 Wheel and Tire Assembly, Rear 2 52" & 61" deck, 20 x 10-8 tire
— JD26 Lug Nut, Rear Wheel 8 Not shown
