Hydrostatic Components - 53
HYDROSTATIC COMPONENTS
NOTES
Ref. No. Part No. Description Qty. Remarks
1 TCA15122 Cap 1
2 TCA15373 Hydraulic Reservoir 1 Includes decals
3 D18379 Hose Clamp 12
4 TCA15078 Wheel Motor 2
5 D14196 Elbow Fitting, Pump End 4 Includes O-ring
6 TCA14966 Pump, LH 1 Includes items 25-35 on page 5
7 TCA14965 Pump, RH 1 Includes items 25-35 on page 5
8 14M7518 Nut 4 M10 x 1.5
9 03M7192 Carriage Bolt, Pump Mounting 4 M10 x 1.5 x 30
10 GDA10137 Oil Filter 1
11 GDA10066 Elbow Fitting 1
12 313270 Elbow Fitting 1
13 14M7517 Lock Nut, Reservoir Mounting 2 M10 x 1.5
14 19M7784 Cap Screw, Reservoir Mounting 2 M10 x 1.5 x 20
15 M86863 Tee Fitting 2
16 D24028 Fitting 4
17 D18394 Hose, High Pressure 4
18 TY22552 Hose, Return AR 25 ft bulk (cut to length)
19 GDA10065 Adapter 1
20 R26375 O-Ring 8 Included with fitting
21 231647 90° Fitting, Upper 2 Includes O-ring
22 231104 Straight Adapter, Lower 2 Includes O-ring
23 231046 90° Fitting, Lower 2
24 D18206 Key 2
25 200950 Hub 2
26 24M7158 Washer 2
27 11H237 Cotter Pin 2
28 TCU19166 Castle Nut 2
— M78480 Tie Straps AR Not shown
29 D14280 Bolt 8 3/8-16 x 1
