-7- G0453/G0454 (Mfg. Since 3/08)
The information contained herein is deemed accurate as of 6/9/2013 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3 Model G0454
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0454 20" PLANER
Product Dimensions:
Weight.............................................................................................................................................................. 771 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................ 39-1/2 x 55-1/2 x 45-7/8 in.
Footprint (Length x Width)............................................................................................................... 29-1/2 x 23-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 920 lbs.
Length x Width x Height....................................................................................................................... 30 x 39 x 49 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 240V, Single-Phase, 60 Hz
Prewired Voltage.................................................................................................................................................. 240V
Full-Load Current Rating........................................................................................................................................ 19A
Minimum Circuit Size.............................................................................................................................................. 30A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length.......................................................................................................................................... 6-1/2 ft.
Power Cord Gauge......................................................................................................................................... 12 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type................................................................................................................................... L6-30
Switch Type.................................................................................................... Magnetic Switch w/Overload Protection
Motors:
Main
Type................................................................................................................. TEFC Capacitor-Start Induction
Horsepower................................................................................................................................................ 5 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 19A
Speed................................................................................................................................................ 3450 RPM
Power Transfer ..................................................................................................................... Triple V-Belt Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Main Specifications:
Operation Info
Max. Cut Width.......................................................................................................................................... 20 in.
Min. Stock Length....................................................................................................................................... 8 in.
Min. Stock Thickness.............................................................................................................................. 3/16 in.
Max. Stock Thickness.................................................................................................................................. 8 in.
No. of Cuts Per Inch............................................................................................................................... 104, 83
No. of Cuts Per Minute............................................................................................................................ 20,000
Cutterhead Speed............................................................................................................................. 4800 RPM
Planing Feed Rate........................................................................................................................... 16, 20 FPM
Max. Cut Depth Planing Full Width........................................................................................................... 1/8 in.
Max. Cut Depth Planing 6 Inch Wide Board............................................................................................. 1/8 in.
G0454 Machine Data Sheet
