Grizzly MOBILE PLANERS G0453 - Manual (Page 52)

-50- G0453/G0454 (Mfg. Since 3/08)
G0453 headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PVMX60 COGGED V-BELT MX-60 57 P0453057 FOAM PIECE
2 P0453002 OIL FILL LABEL 58 PFB09M FLANGE BOLT M6-1 X 10
3 P0453003 CHAIN 06B-1 X 49 31LINKS 59 P0453059 TOP COVER
4 P0453004 CHAIN 06B-1 X 63 24LINKS 60 PFH04M FLAT HD SCR M6-1 X 8
5 PW03M FLAT WASHER 6MM 61 P0453061 CUT LIMIT PLATE
6 PSB26M CAP SCREW M6-1 X 12 62 PSS06M SET SCREW M8-1.25 X 16
7 P0453007 MAGNETIC SWITCH ASSEMBLY 63 PEC05M E-CLIP 15MM
7-1 P0453007-1 MAGNETIC SWITCH COVER 64 P0453064 ANTI-KICKBACK ROD
7-2 P0453007-2 MAGNETIC SWITCH BACK 65 P0453065 COLLAR
7-3 P0453007-3 CONTACTOR NHD 09D 220V 66 P0453066 ANTI-KICKBACK FINGER
7-4 P0453007-4 OL RELAY NHD BTH-21 17-21A 67 PFB10M FLANGE BOLT M6-1 X 15
8 P0453008 MAGNETIC SWITCH PLATE 68 P0453068 CHIP DEFLECTOR
9 P0453009 HANDWHEEL LABEL 69 PSS25M SET SCREW M6-1 X 20
11 P0453011 COLLAR 70 P0453070 SHAFT
12 P0453012 EXTENSION SPRING 71 PFB01M FLANGE BOLT M6-1 X 12
13 PSS13M SET SCREW M10-1.5 X 12 72 P0453072 HOLDDOWN PLATE
14 P0453014 HANGER 73 PN01M HEX NUT M6-1
15 P0453015 SHAFT 74 PSS58M SET SCREW M6-1 X 18
16 P0453016 BRACKET 75 P0453075 CHIP BREAKER
17 P0453017 IDLER PULLEY 76 PN09M HEX NUT M12-1.75
18 P0453018 IDLER SHAFT 77 PLW05M LOCK WASHER 12MM
20 P0453020 COLLAR 78 PR03M EXT RETAINING RING 12MM
21 P0453021 STAR KNOB M8-1.25 79 P0453079 LOCKING ROD
25 P0453025 BELT COVER 80 P0453080 OUTFEED ROLLER SPROCKET
26 PFH02M FLAT HD SCR M6-1 X 12 81 P0453081 OUTFEED ROLLER
27 P0453027 SPECIAL BOLT 82 PB83M HEX BOLT M6-1 X 16
28 P0453028 BELT GUARD 83 PW03M FLAT WASHER 6MM
29 PFB09M FLANGE BOLT M6-1 X 10 84 P0453084 INFEED ROLLER SPROCKET
30 P0453030 SAFETY HATCH 86 PB03M HEX BOLT M8-1.25 X 16
31 PSB45M CAP SCREW M8-1.25 X 45 88 PN06M HEX NUT M5-.8
33 P0453033 CHAIN DRIVE COVER 89 PSS53M SET SCREW M5-.8 X 12
34 P0453034 POINTER 90 P0453090 PLATE
35 PS68M PHLP HD SCR M6-1 X 10 91 P0453091 SPECIAL OILER SET SCREW
36 PW03M FLAT WASHER 6MM 92 P0453092 COMPRESSION SPRING
37 PS14M PHLP HD SCR M6-1 X 12 93 P0453093 ROLLER BUSHING BLOCK
38 P0453038 SCALE 94 PK08M KEY 5 X 5 X 16
39 P0453039 HANDLE 95 P0453095 INFEED ROLLER
40 P0453040 HANDWHEEL 96 PK09M KEY 8 X 8 X 35
41 PN09M HEX NUT M12-1.75 97 P0453097 MOTOR PULLEY 60HZ
42 PW06M FLAT WASHER 12MM 98 PB09M HEX BOLT M8-1.25 X 20
43 PK48M KEY 4 X 4 X 20 99 P0453099 COLLAR
44 P0453044 WORM GEAR 100 P0453100 CUTTERHEAD PULLEY 60HZ
45 P6201 BALL BEARING 6201ZZ 101 PEC015M E-CLIP 8MM
46 PR29M INT RETAINING RING 32MM 102 P0453102 KNIFE GAUGE SHAFT
47 PSB137M CAP SCREW M5-.8 X 55 103 P0453103 KNIFE GAUGE FOOT
48 P0453048 WORM HOUSING 104 P0453104 KNIFE (SET OF 3)
48A P0453048A WORM HOUSING ASSEMBLY 105 P0453105 GIB SCREW
49 P0453049 RETURN ROLLER 106 P0453106 GIB
50 PSB20M CAP SCREW M5-.8 X 14 107 PSB24M CAP SCREW M5-.8 X 16
51A P0453051A ROLLER STAND 3.505" V2.01.08 108 P0453108 ADJUSTING NUT
52 PW03M FLAT WASHER 6MM 109 P6205 BALL BEARING 6205ZZ
53 PN01M HEX NUT M6-1 110 P6204 BALL BEARING 6204ZZ
54 PB04M HEX BOLT M6-1 X 10 111 P0453111 CUTTERHEAD
55 PB09M HEX BOLT M8-1.25 X 20 112 P0453112 HEAD CASTING
56 P0453056 DUST HOOD 118 P0453118 KNIFE GAUGE ASSEMBLY
