Edge 500 Owner’s Manual

ANT+ Sensors

2. Use a coin to twist the cover

counter-clockwise so the arrow on

the cover points to

OPEN

Remove the cover and battery.

4. Wait 30 seconds.
5. Insert the new battery with the

positive side facing up.
NOTE: Be careful not to damage

or lose the O-ring gasket on the

cover.

6. Use a coin to twist the cover

clockwise so the arrow on the cover

points to

CLOSE

Installing the GSC 10

Both magnets must be aligned with

their respective indication lines for the

Edge to receive data.
1. Place the GSC 10 on the rear chain

stay (on the side opposite the drive

train).
NOTE: Place the flat rubber pad

or the triangle-shaped rubber pad

between the GSC 10 and the chain

stay for stability.
