GIGABYTE GN-B41G - Manual (Page 83)

GN-B41G Wireless Broadband Router
Appendix B: Specifications
General
Standards IEEE802.3(10Base-T), IEEE802.3u(100Base-TX),
IEEE802.11b/g(Wireless)
Ports / Buttons LAN – 4 ports 10/100 Ethernet (auto-MDIX), RJ-45
WAN - 10/100 Ethernet (auto-MDIX), RJ-45
One Init (Reset) button
Power External; 5V DC, 2A
Wireless
Frequency Band 2412 ~ 2483 MHz (subject to local regulation)
Modulation Technology OFDM and DSSS
Modulation Techniques 64QAM, 16QAM, QPSK, BPSK, DBPSK, DQPSK, CCK
Data Rates
54, 48, 36, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps (auto fallback)
Output power 20 dBm @ Nominal Temp Range
Receive Sensitivity -68 dBm @ 54Mbps date rate at nominal temperature
Antenna One external antenna
Wireless Range Outdoor: 100 to 300m Indoor: 30 to 100m
Regulatory and Environmental Compliance
EMC certification FCC part (USA)
CE(Europe)
Temperature Range Operating: 0 to 40 °C,
Storage: -20 to 65 °C
Humidity 10% ~ 85% Non-condensing
Protocols
Routing Protocols Dynamic, Static Routing with TCP/IP
NAT, PPTP, PPPoE
VPN Pass-Through (IPSec, L2TP)
DHCP (Client & Server)
Security 64/128 bit WEP; WPA-PSK; WPA
Mechanical
LEDs Power/Status; WLAN; LAN (1-4); WAN
Gross Weight 240± 5g
Dimensions 110mm x 160mm x 25mm
81
