12

308-457

Parts

Model 237–418, Series A

Includes items 1 to 37

Ref
No.

Part No.

Description

Qty

Ref
No.

Part No.

Description

Qty

1

223–596

23:1 RATIO MONARK PUMP

See 307–619 for parts

1

2

224–044

CART,

portable

See 308–136 for pa

rts

1

3

223–283

AIR ASSISTED AIRLESS
SPRAY GUN

See 308–176 for parts

1

4

182–411

SPRAY TIP,

0.011 orifice,

8–10” (203–254 mm) fan width

1

5

218–029

FLUID FILTER

See 307–273 for parts

1

6

214–698

FLUID HOSE,

3/16” x 25’ (15.2 m),

nylon, spring guards both ends,
1/4–18 npsm(fbe)

1

7

210–867

AIR HOSE,

cpld 1/4 npsm (fbe)

1/4” ID x 25’ (6.3 mm ID x 7.6 m)

1

8

104–267

AIR REGULATOR

0–125 psi (0–9 bar) range
See 308–167 for part

s

2

9

101–180

AIR PRESSURE GAUGE

0–200 psi (0–14 bar)

2

10

161–037

90

_

SWIVEL ADAPTER UNION

1/2 npt(m) x 3/8 npsm(f) swivel

1

11

204–560

AIR HOSE,

buna-N, 3/8” (10 mm) ID,

cpld 3/8 npt(mbe), 18” (457 mm) long

1

12

222–297

45

_

SWIVEL ADAPTER UNION,

1/2 npt(m) x 1/2 npsm(f) swivel

1

13

158–491

NIPPLE,

1/2 npt, 1.625” (41 mm) long

1

14

107–142

BLEED–TYPE AIR VALVE,

1/2 npt (f)

1

15

102–814

FLUID PRESSURE GAUGE

1

16

166–999

ELBOW,

reducing street,

1/2 npt(m) x 1/4 npt(f)

1

17

162–453

NIPPLE,

1/4 npt x 1/4 npsm

2

18

214–960

SUCTION HOSE,

3/4 npt (mbe),

3/4 ” ID x 3.5’ (19 mm ID x 1.06 m)

1

19

165–767

SUCTION TUBE,

3/4 npt(f)

1

20

100–349

FLUID INTAKE ELBOW,

3/4 npt(f)

1

21

100–016

LOCKWASHER,

1/4” spring

2

23

155–665

SWIVEL UNION,

3/8 npt(m) x 3/8 npsm(f)

1

24

206–994

THROAT SEAL LIQUID,

8 oz

.

1

25

156–849

NIPPLE,

3/8 npt x 3/8–18.6 sf

1

26

210–658

BALL VALVE,

3/8 npt (mbe),

see 306–861 for parts

1

27

156–877

NIPPLE,

1/2 npt, 2.5” (63.5 mm)

2

28

188–595

PUMP MOUNTING PLATE

1

29

102–254

SCREW,

hex hd, 1/4–20 x

7/8” (22 mm) long

2

30

237–569

GROUND WIRE and CLAMP

12 gauge (1.5 mm

2

), 25’ (7.6 m)

1

31

150–286

ADAPTER

1

32

165–472

ELBOW, 90

_

; 3/8 npt (fbe)

1

33

100–509

PLUG,

1/4 npt sq hd pipe

3

34

179–749

AIR MANIFOLD

, 1/2 npt inlet,

two 1/2 npt outlets

1

35

100–015

NUT

, hex; 1/4–20

2

36

100–840

ELBOW;

1/4 npt (m x f)

1

37

160–790

NIPPLE

1

Manual Change

Summary

This manual was updated to correct the parts drawing
on page 13. The following parts lists changes were
also made.

Assembly
Changed

Part
Status

Ref
No.

Part No.

Name

237–418
Package

Add

Old
New

31

37
37

150–286

150–286
160–790

Adapter

Nipple
Nipple
