CHAPTER 12: GROUPS 4, 5, AND 6 – SET LIMITS AND RELAYS
78
EPM 5000 series Advanced Power Meters GE Multilin
MAX/MIN
LIMITS
KVAR
PF
KW
KVA
FREQ
KWH
KVAH
AC VOLTS
AC AMPS
POWER
N
C
B
A
MAX
MIN
A
N
B
N
C
N
A
B
B
C
C
A
LM2
LM1
NEXT
PHASE
VOLTS AMPS
POWER
MAX/MIN
LIMITS
KVAR
PF
KW
KVA
FREQ
KWH
KVAH
AC VOLTS
AC AMPS
POWER
N
C
B
A
MAX
MIN
A
N
B
N
C
N
A
B
B
C
C
A
LM2
LM1
NEXT
PHASE
VOLTS AMPS
POWER
Step 6:
a. Press VOLTS to scroll through digits.
b. Press AMPS to select.
c. At the last digit, press AMPS twice to store limit
programming.
!
Wait 3 seconds and the display updates with
the new programming value.
Step 7:
a. Press VOLTS to program the other limits and repeat
this procedure.
b. Press MAX/MIN/LIMITS TO PROGRAM
ANOTHER Function (refer to Step 2).
See Chapter 14 to Exit.
