GE EPM 5200 User Manual
Page 14
CHAPTER 3: ELECTRICAL INSTALLATION
10
EPM 5000 series Advanced Power Meters GE Multilin
+
-
POWER
7
6
5
4
3
2
1
8
9
10 11
12 13
PORT
L1
L
LINE
A
B
C
LOAD
BACK VIEW
II. Three-Phase, Three-Wire Open Delta with two CTs and two PTs
Note: Remember to make sure Open Delta bit is programmed in the meter (see section 9.4).
+
-
POWER
7
6
5
4
3
2
1
8
9
10 11
12 13
PORT
L1
L
LINE
A
B
C
LOAD
BACK VIEW
III. Three-Phase, Three-Wire Open Delta with three CTs and two PTs
Note: Remember to make sure Open Delta bit is programmed in the meter (see Chapter 9).
