BIOS Setup
English
- 43 -
Onboard Serial P ort 2
Auto BIOS w ill autom atically s etup the port 2 address.
3F8/ IRQ4 Enable onboard Serial port 2 and address is 3F8.
2F8/ IRQ3 Enable onboard Serial port 2 and address is 2F8. (Default v alue)
3E8/ IRQ4 Enable onboard Serial port 2 and address is 3E8.
2E8/ IRQ3 Enable onboard Serial port 2 and address is 2E8.
Disabled Disable onboard Serial port 2.
UART Mode Select
This item allow s y ou to determine w hich infrared(IR) function of onboard I/O chip.
Normal Set onboard I/O chip using as standard serial port. (Default v alue)
IrDA Set onboard I/O chip UAR T to IrDA Mode.
ASKIR Set onboard I/O chip UART to ASKIR Mode.
UR2 Duplex Mode
This function w ill av ailable w hen "UART Mode Select" doesn't set at Normal.
Half IR Function Duplex Half. (Default v alue)
Full IR F unction Duplex F ull.
Onboard Parallel Port
378/ IRQ7 Enable onboard LPT port and address is 378/IRQ7. (Default v alue)
278/ IRQ5 Enable onboard LPT port and address is 278/ IRQ5.
Disabled Disable onboard LPT port.
3BC/ IRQ7 Enable onboard LPT port and address is 3BC/ IRQ7.
Parallel Port Mode
SPP Using Parallel port as Standard Parallel Port. (Default v alue)
EPP Using Parallel port as Enhanced Parallel Port.
ECP Using Parallel port as Ex tended Capabilities Port.
ECP+EPP Using Parallel port as ECP & EPP mode.
Game Port Address
201 Set Game Port Address to 201. (Default v alue)
209 Set Game Port Address to 209.
Disabled Disable this function.
Midi Port Address
300 Set M idi Port Address to 300.
330 Set M idi Port Address to 330
Disabled Disable this function. (Default v alue)
Midi Port IRQ
5 Set Midi Port IRQ to 5.
10 Set M idi Port IRQ to 10. (Default v alue)
