G0752 motor wiring diagram, 110 vac – Grizzly 10" x 22" Benchtop Lathe G0602 User Manual
Page 75
Model G0602/G0752 (Mfg. Since 11/12)
-73-
figure 114. right motor junction box.
figure 113. left motor junction box.
g0752 motor Wiring diagram
Motor 1HP 220V 3PH
Motor Fan
110V 30W 1PH
Ground
Neutral
Hot
Ground
110 VAC
5-15 Plug
(As Recommended)
U1
W1
N1
L1
PE
L
N
V1
PE
to Wiring
Box
page 69
to Wiring
Box
page 69
to Wiring
Box
page 69
