39
To Adjust Recline on Base:
Turn the knob clockwise to the desired setting to
lower the foot
➊.
Turn the knob counter clockwise to raise the foot
➋.
If there is still orange in the level indicator when
the foot is completely extended then raise the
foot and place a rolled towel under the foot
➌
until ONLY blue shows.
When using only the infant restraint, if there is
still orange in the level indicator when the infant
restraint is resting on the vehicle seat then place
a rolled towel under the infant restraint ➍ until
ONLY blue shows.
Readjust the vehicle seat belt as necessary
to secure the infant restraint firmly in the
vehicle seat.
➊
➌
➋
➍
