37
1. For ease of installation, extend
LATCH to its maximum length
and remove from storage bars.
2. Position base in vehicle seat as
shown.
3. Make sure
LATCH is through
vehicle/LATCH belt path normally
used for vehicle seat belt.
➋.
Belt must lay flat and not be twisted.
4. Hook
Connectors to vehicle lower
anchors. Pull firmly on
Connectors to
be sure they are attached
➌.
5. Tighten
LATCH by pushing down
hard on base and pulling the
adjustment belt
➍.
6.
NEVER put two LATCH connectors
on one vehicle
LATCH anchor unless
specifically allowed by the vehicle
manufacturer
➎.
7. Test infant restraint for secure
installation as described in infant
restraint
„ Final Safety Check‰ page.40.
8. Check that the
LATCH stays tight
and does not slip from the tightened
position. If it does not stay tight, try another
seating position or contact Graco at 1-800-345-4109.
7.3 Using LATCH to install Base
➋
➍
➎
➌
