Shoulder Straps for a SMALLER Baby:
Use the lower harness slots
➊ (if they are even with or just below
your childÊ s shoulders) and the upper strap loops
➋. The ends of the
straps must hang in front of the metal junction plate as shown in ➋,
not as shown in
➌.
CHECK that the loops are completely
within junction plate slots ➍.
CHECK that straps are secure by pulling
on them.
Shoulder Straps for a LARGER Baby:
Use middle or upper harness slots ➎ and the end strap loops ➏.
CHECK that the loops
are completely within
junction plate slots
➏.
CHECK that straps
are secure by pulling
on them.
22
gracoba by com
➌ ➊ ➋
➍
➏
gracoba by.com
➎
