REF PART # DESCRIPTION REF PART # DESCRIPTION
G3183 Hollow Chisel Mortiser -21-
101 P3183001 CASTING BASE
102 PLW04M LOCK WASHER 8mm
103 PSB14M CAP SCREW M8-1.25x20mm
104 P3183104 COLUMN
105 PSS16M SETSCREW M8-1.25x10mm
106 P3183006 HEADSTOCK
107 P3183007 DEPTH STOP ROD
108 P3183008 MOTOR
109 P3183009 RACK
110 PSB26M CAP SCREW M6-1.0x12mm
111 PLN04M LOCK NUT M8-1.25
112 PB26M HEX BOLT M8-1.25x30mm
113 P3183013 TABLE
114 P3183014 FENCE
115 P3183015 HOLD DOWN
116 P3183016 LOCK HANDLE
117 P3183017 BRASS SCREW
118 PSS02M SETSCREW M6-1.0x6mm
119 P3183019 PINION SHAFT
120 PK19M KEY 5x5x14mm
121 P3183021 COLLAR
122 P3183022 GEAR
123 P3183123 LOWER CYL. FITTING
125 P3183125 HYDRAULIC CYLINDER
126 P3183026 LEFT ADJ. GEAR
127 PRP30M ROLL PIN 5x50mm
128 P3183028 HEX NUT M16-2.0
129 P3183029 RIGHT ADJ. GEAR
130 P3183130 UPPER CYL. FITTING
131 P3183031 HANDLE BAR
132 P3183032 HANDLE GRIP
133 PSB24M CAP SCREW M5-0.8x16mm
134 P3183034 SPINDLE EXTENSION
135 P3183035 CHUCK
136 SEE CATALOG
137A P3183037A BUSHING 5 ⁄
8
''
137B P3183037B BUSHING 3 ⁄
4
''
138 P3183042 CAP
139 PFH06M FLAT HD SCR M6-1.0x12mm
140 P3183040 COVER
141 P3183041 KNOB
142 P3183047 SWITCH BASE
143 P3183046 SWITCH COVER
144 PSW07 SWITCH
145 P3183044 BRASS PIN
146 P3183048 SPRING
147 PSS10M SETSCREW M10-1.5x20mm
148 PN02M HEX NUT M10-1.5
149 P3183046A SCREW
150 P3183052 POWER CORD
151 P3183051 CHUCK KEY
152 PAW 04M ALLEN WRENCH 4mm
153 PAW 05M ALLEN WRENCH 5mm
154 P3183154 LOGO PLATE
