G5787 Meatcutting Bandsaw -17-
Meat Grinder
The Model G5787 comes with a meat grinder.
Before assembling this for use, clean and sanitize
its parts. See
Section 5: Sanitization for details
on sanitizing. Figure 25 shows the meat grinder
components.
Figure 25. Meat grinder components .
Figure 26. Installing meat grinder.
Figure 27. Attaching sausage stuffer.
To install the meat grinder:
1. Line up the fixed key on the meat grinder to
the keyway on the housing shown in
Figure
26 .
2. Spin the pulley wheel by hand to line up the
grinder tongue so it will fit into the groove on
the auger.
3. Slide the meat grinder all the way into the
housing and tighten the split collar to secure
the grinder in place.
Keyway
The meat grinder comes with a sausage stuffer
attachment. To install this:
1. Remove the collar from the end of the meat
grinder.
2. Fit the collar over the sausage stuffer.
3. Place the collar back on the meat grinder as
shown in
Figure 27 , and thread it tight so it
is secured to the meat grinder.
The meat grinder should not be attached
to the saw when not in use. The open
chute and spinning auger easily invite an
accident if not being attended to.
