Guardian Technologies C2369 User Manual
Page 12
Generac
®
Power Systems, Inc.
35
ITEM
PART NO. QTY. DESCRIPTION
1
A9909
1
CONTROL PANEL
2
A1801
1
ASSEMBLY, ENGINE BATTERY
CHARGER
3
83048
1
ASSEMBLY, VOLTAGE
REGULATOR
4
C2174
1
RELAY, 12V. 25A SPST
5
75210A
1
TERMINAL BLOCK
6
40213
4
PCB SUPPORT, SNAP-IN
7
C1537
1
ASSEMBLY, PCB
CONTROLLER
8
65795
1
RECTIFIER, BATTERY
CHARGER
9
32300
1
HOLDER, FUSE
10
22676
1
FUSE, 15 AMP.
11
33873
1
SWITCH, DPDT-ROCKER
12
75234
1
RESISTER, 1 OHM 25W
13
A2769
1
LUG, GROUND 8-TABS
14
23484F
3
SNAP BUSHING
15
75476
2
M4-0.7 x 16 PHILLIPS
PAN HEAD
16
22264
9
M4 LOCK WASHER
17
51715
5
M4-0.7 HEX NUT
18
80077
1
M4-0.7 x 20 PHILLIPS
PAN HEAD
19
43182
6
M3 LOCK WASHER
20
43181
6
M3-0.5 x 10 PAN HEAD
21
86729
1
STARTER CONTACTOR
22
C1227
1
DECAL, CONTROL PANEL
(NOT SHOWN)
23
54502
1
CIRCUIT BREAKER AUTO
RESET
24
A1495
2
M4-0.7 x 10 TAPTITE
25
75235
4
M5-0.8 x 30 HEX HD.
26
22985
1
M4/#6 FLAT WASHER
ITEM
PART NO. QTY. DESCRIPTION
27
92113
1
SWITCH SPDT (MOM)
28
51714
4
M3-0.5 HEX NUT
29
C1457
1
HOURMETER
30
A2110
2
SWAGEFORM, ¼"-20
31
99076
1
TRANSFORMER, 16V 56VA
32
74908
3
M5-0.8 x 10 TAPTITE
33
A2053
1
M6-1.0 x 65 HEX HEAD
34
22473
1
M6 FLAT WASHER
35
22097
3
M6 LOCK WASHER
36
49813
1
M6-1.0 HEX NUT
37
22471
2
#8-32 HEX NUT
38
49226
4
M5 LOCK WASHER
39
51716
4
M5-0.8 HEX NUT
40
36261
2
POP RIVET 1/8 x .23
41
A9896
1
BOX COVER
42
A9947B
1
45A CIRCUIT BREAKER (10KW)
A9947A
1
35A CIRCUIT BREAKER (8KW)
A9947
1
25A CIRCUIT BREAKER (6KW)
43
A9992A
8
TERMINAL BLOCK
44
A9992D
1
NUMBER STRIP
45
A9992B
2
END BRACKETS
46
A9992C
1
INSULATING PLATE
47
A9872
1
DIN RAIL
48
A9895
1
CONNECTION BOX
49
75475
4
M4 x 0.7 x 10 PMMS
50
38150
6
M4 FLAT WASHER
51
C2657
1
TRANSFORMER, 16V 6VA
52
22155
2
#6 LOCK WASHER
53
C1381
2
#6-32 x ¼" PHILLIPS PAN
HEAD, SELF TAPPING
54
22127
2
¼-20 HEX NUT
55
C1226
1
HARNESS (NOT SHOWN)
56
31879
2
#4 FLAT WASHER
Section 7 — Exploded Views and Parts Lists
Guardian Air-cooled 6 kW, 8 kW and 10 kW Generators
Control Panel Assembly – Drawing No. C2373-
