Guardian Technologies C2369 User Manual
Page 10
Generac
®
Power Systems, Inc.
33
ITEM
PART NO. QTY. DESCRIPTION
1
C1350A
1
WRAPPER, VALLEY
2
C1351A
1
WRAPPER, CYLINDER #1
3
C1354A
1
STARTER, WRAPPER
4
C1353A
1
WRAPPER, CRANKCASE
5
C1355
1
10KW COVER, ENGINE
C1355A
1
8KW COVER, ENGINE
6
C1352A
1
WRAPPER, CYLINDER
#2-BACK
7
C1468A
1
WRAPPER, CYLINDER
#2-FRONT
8
66480
1
GASKET, AIR CLEANER
9
C1460
1
CARBURETOR
10
C1285
1
MANIFOLD INTAKE
11
C1625
2
GASKET, INTAKE
12
C2784
1
TUBE, INTAKE
13
35685
1
CLAMP, #28
14
70941
1
FILTER, AIR
15
C1626
1
GASKET, CARBURETOR
16
C2689
4
M6-1.0 x 16 SOCKET
HEAD SCREW
17
39287
2
M8-1.25 x 45 HEX HEAD BOLT
18
A9736
1
FRAME, 10KW
A9736A
1
FRAME, 8KW
19
22287
2
¼-20 x 3/4" HEX HEAD BOLT
20
C2421
1
ROD, SPEED CONTROL
21
C2425
1
BRACKET, SPEED CONTROL
22
C2424
1
CAP, SPRING
23
C2422
1
SPRING, SPEED CONTROL
24
C2423
1
NUT, SPEED CONTROL
25
74908
4
M5-0.8 x 10 TAPTITE
26
22413
4
¼-20 x 1" HEX HEAD BOLT
27
C1702
1
BREATHER HOSE
28
A9027
1
OIL ADAPTOR
29
A9028
1
OIL ADAPTOR BOLT
30
C1557
1
O-RING, 13/16" I.D.
31
C1547
1
O-RING, 7/8"
32
C1546
1
O-RING, 2-3/8"
33
74948
4
FITTING, 5/16" COMPRESSION
34
C1623
1
OIL TUBE, RETURN
35
C1622
1
OIL TUBE, OUT
36
A6898
1
OIL FILTER SUPPORT
37
70185
1
OIL FILTER
38
60108
1
OIL PRESSURE SWITCH
39
11-74260
1
STARTER CABLE
40
22507
6
¼-20 x ½" HEX HEAD BOLT
ITEM
PART NO. QTY. DESCRIPTION
41
56893
29
10-24 x ½ "CRIMPTITE
42
A2311
2
¼-20 x 1" TAPTITE
43
C1349
1
SCROLL, FLYWHEEL
44
C1677
1
GOVERNOR BRACKET
45
C1676
1
GOVERNOR LEVER
46
C1679
1
GOVERNOR LINKAGE
47
C1680
1
SPRING, ANTI-LASH
48
C1859
1
SPRING, IDLE
49
22097
16
¼" LOCK WASHER
50
22717B
1
GROMMET
51
22717A
1
GROMMET
52
22127
2
¼-20 HEX NUT
53
C2420
1
KEY
54
65852
1
CLIP
55
C2441
1
WIRE DIODE ASSEMBLY
56
C1863
1
BAFFLE
57
36261
2
POP RIVET, 1/8" x .23 S.S.
58
22129
6
5/16" LOCK WASHER
59
C2693
1
CARRIAGE BOLT ¼-20 x 1-3/8"
60
49811
1
M6 FLAT WASHER
61
91159
2
RUBBER BUSHING
62
74962A
1
SPRING, GOVERNOR
63
C2145
1
GASKET, SET ENGINE COVER
64
74902
2
SHIELD WRAPPER
65
38593
1
90 DEG.ST. ELBOW 3/8"
66
C1983
1
3/8" x 11-1/4" PIPE
67
A7299
1
DIPSTICK TUBE
68
A8875
1
DIPSTICK & CAP
69
43790A
1
90 DEG. HOSE FITTING
3/8" x 3/8"
70
C2078
1
OIL DRAIN HOSE
71
75246
4
3/8-16 x 1-1/4" TAPTITE
72
A4456
1
3/8" SPECIAL LOCK WASHER
73
A9820
1
EXHAUST MANIFOLD
74
C1624
2
EXHAUST GASKET
75
75789
4
5/16-18 x ¾" SOCKET
HEAD SCREW
76
C1950
2
GASKET, EXHAUST
77
23897
6
#10 FLAT WASHER
78
23762
1
STAR WASHER #10
79
73132
2
BOOT, SPARK PLUG
80
C2866
1
CLAMP
81
A9816
1
EXHAUST FLEX
82
C2418
1
NUT, FLYWHEEL
83
C2419
1
WASHER, FLYWHEEL
84
C2824
1
TAP-R 10-32 x 9/16"
Section 7 — Exploded Views and Parts Lists
Guardian 8 kW and 10 kW Generators
GN-724 Engine Accessories and Sheet Metal – Drawing No. C2371-
