-11-
G8144Z/G8145Z/G8146Z
Vertical Metal Cutting Bandsaw
Control Panel Identification
Figure 3. Control panel identification.
A
B
C
D
E
F
H
I
A. Digital Speed Display (FPM)
B. Variable Speed Control
C. Welding ON Button
D. Annealing ON Button
E. Clamping Pressure Dial
F. Welder Jaws
G. Welding Jaw Lock Levers
H. Grinding Wheel ON/OFF Switch
I. Grinding Wheel
Figure 4. Model G8144Z/G8145Z power switch.
Model G8146Z only:
J. Power Switch & Key
K. Power Lamp
L. Emergency Stop Button
M. Bandsaw Start Button
Figure 5. Model G8146Z power control panel.
J
K
L
M
G
