Page 12
-10-
G8144Z/G8145Z/G8146Z
Vertical Metal Cutting Bandsaw
Figure 2. Model G8146Z basic identification.
Model G8146Z Basic Identification
Front View
Rear View
A
B
C
D
E
F
G
H
I
J
K
L
N
O
P
Q
M
A. Blade Shear
B. Upper Wheel Door
C. Guide Post Elevation Handwheel
D. Guide Post Lock Knob
E. Work Light (220V)
F. Air Hose & Jet
G. Blade Tension Handwheel
H. Table Tilt Scale
I. Motor Access Panel
J. Machine Mounting Flange
K. Lower Wheel Door
L. Lower Blade Guide Assembly
M. Table
N. Upper Blade Guide Assembly
O. Blade Post
P. Bandsaw Power Control Panel
Q. Blade Welding Station
