Magnum H80B and H80P Personal Hubs User Guide (07/95)
GARRETT
17
3.5 Ethernet Media Connections
Magnum H80Bs and H80P are equipped with eight
sheilded twisted pair ports and a BNC or DTE (male AUI) port. The
following sections give instructions for installing each of these media
types.
3.5.1 Twisted Pair Connections
1. Using standard
10BASE-T media, insert the
male plug on one end of the
network cable into one of
the RJ-45 female ports on
the Personal Hub. Even
though the hub's plugs are of
the shielded type, they will
accept and operate properly
with both shielded and unshielded type RJ-45 twisted pair wiring.
2. Connect the other end of each network segment to the
applicable workstation or user device. The "LINK" LED will be lit
for each port when the connection is made on both ends of the
segment, and when the DC power is present at each end as well, i.e.,
when the segment circuit is established and is ready to use.
3. For the switched port up-link option, see Section 3.6.
