Magnum H80B and H80P Personal Hubs User Guide (07/95)
GARRETT
14
3.0 Installation
This section describes the installation of Magnum H80B
and H80P Personal Hubs, including mounting options and cable
connections.
3.1 Magnum H80B Installation
The installation of a Magnum H80B Personal Hub is a very
simple procedure. Locate an AC receptacle that is within six feet (2
meters) of the intended hub location and plug in the external power
supply unit (provided as part of the unit). The small DC power cord
from the power supply plugs into the matching rear power jack of the
Personal Hub, and when power is applied the green "PWR" LED will
be illuminated.
The external power supply unit supplied is one of two
types; one version for AC input power of 115 vac 60 Hz, and one
version for 230 vac 50 Hz. Examine the power supply to make sure
the version you have is the right type for your AC power system.
The 115 vac version has a small transformer integral with a
convenience power outlet plug, and a lightweight DC power cord to
the applicable power jack on the hub. The 230 vac version has a
small transformer integral with an IEC-type power plug for a user-
supplied AC power cord with a convenience power outlet plug. It
also includes a lightweight DC power cord to the applicable power
jack on the Personal Hub unit.
