Magnum H80B and H80P Personal Hubs User Guide (07/95)
GARRETT
16
stability if desired. When properly installed, the top-view LED status
indicators will be in plain view and easy to read. Plug in two or
more Ethernet cable segments, and your network is in operation.
The rugged steel case of the Personal Hub will protect it
from accidental damage in an office or lab workplace setting. Keep
an open area around the unit so that convection cooling can occur
while the unit is in operation.
3.4 Wall (or Vertical Surface) Mounting
A piece of Velcro mounting tape is supplied with the unit,
and may be used to mount a Personal Hub in a vertical position.
Stick one side of the Velcro on the bottom of the hub between the
rubber feet. Stick the other side of the Velcro to the desired vertical
mounting location. This permits the compact Personal Hub to be
mounted on a wall surface, on the side of a server unit cabinet, on the
back of a desk, or in other similar convenient locations in the
workplace where the associated cables are out of the way.
As an alternative to Velcro for vertical surface mounting,
small brackets for mounting with screws may be used. These items
are included in the package. The metal screws in each side of the
Personal Hub’s case may be used to attach the brackets. Use of the
optional brackets permits the Personal Hub to be mounted in almost
any desired orientation or position.
