Magnum H80B and H80P Personal Hubs User Guide (07/95)
GARRETT
12
The Magnum H80B offers a simple means of creating a
small workgroup network from a single BNC port. The installer
simply connects the existing BNC tap to the BNC port of the H80B
with a standard ThinNet (10BASE2) segment. By using the internal
termination of the H80B, no "tee" conector is required (unless the
segment must extend beyond the H80B unit). Then, power is
connected by plugging the external power supply unit into an AC
power receptacle, and plugging the DC power plug into the jack on
the back of the Personal Hub. In minutes, eight twisted pair ports are
available for other networked devices.
