NR = Heating Temperature Rise Not Recommended.
NOTE: The shaded area indicates ranges in excess of
maximum external static pressure allowable when
heating. For satisfactory operation, external static
pressure should not exceed 0.5" w.c.
BLOWER PERFORMANCE DATA - SINGLE PHASE
Unit
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS RISE
0.1 1,125 162 1.44 61 1,466 315 2.67 47 1,780 496 3.33 NR
0.2 1,049 168 1.53 65 1,384 322 2.74 50 1,730 506 3.89 NR
0.3 1,000 178 1.60 69 1,347 329 2.78 51 1,664 520 4.01 NR
0.4 910 184 1.64 75 1,291 341 2.83 53 1,608 526 4.03 NR
0.5 857 197 1.75 NR 1,237 350 2.90 55 1,568 532 4.12 NR
0.6 809 201 1.83 NR 1,185 362 3.05 58 1,515 546 4.14 45
0.7 739 207 1.86 NR 1,134 369 3.09 60 1,477 552 4.18 46
0.8 703 218 1.96 NR 1,087 382 3.21 63 1,422 562 4.23 48
Unit
Static CFM WATTS AMPS CFM WATTS AMPS
0.1 1,942 649 4.83 2,067 792 5.81
0.2 1,883 657 4.87 2,030 811 5.85
0.3 1,859 670 4.96 1,982 814 5.88
0.4 1,827 675 4.97 1,909 808 5.86
0.5 1,749 683 4.99 1,842 798 5.85
0.6 1,706 693 5.10 1,789 772 5.65
0.7 1,655 703 5.12 1,703 763 5.58
0.8 1,588 705 5.11 1,618 732 5.29
Unit
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS RISE
0.1 1,125 162 1.44 NR 1,466 315 2.67 58 1,780 496 3.33 48
0.2 1,049 168 1.53 NR 1,384 322 2.74 62 1,730 506 3.89 49
0.3 1,000 178 1.60 NR 1,347 329 2.78 63 1,664 520 4.01 51
0.4 910 184 1.64 NR 1,291 341 2.83 66 1,608 526 4.03 53
0.5 857 197 1.75 NR 1,237 350 2.90 69 1,568 532 4.12 54
0.6 809 201 1.83 NR 1,185 362 3.05 72 1,515 546 4.14 56
0.7 739 207 1.86 NR 1,134 369 3.09 NR 1,477 552 4.18 58
0.8 703 218 1.96 NR 1,087 382 3.21 NR 1,422 562 4.23 60
Unit
Static CFM WATTS AMPS CFM WATTS AMPS
0.1 1,942 649 4.83 2,067 792 5.81
0.2 1,883 657 4.87 2,030 811 5.85
0.3 1,859 670 4.96 1,982 814 5.88
0.4 1,827 675 4.97 1,909 808 5.86
0.5 1,749 683 4.99 1,842 798 5.85
0.6 1,706 693 5.10 1,789 772 5.65
0.7 1,655 703 5.12 1,703 763 5.58
0.8 1,588 705 5.11 1,618 732 5.29
Unit
Static CFM WATTS AMPS RISE CFM WATTS AMPS RISE CFM WATTS AMPS RISE
0.1 1,125 162 1.44 NR 1,466 315 2.67 71 1,780 496 3.33 59
0.2 1,049 168 1.53 NR 1,384 322 2.74 NR 1,730 506 3.89 60
0.3 1,000 178 1.60 NR 1,347 329 2.78 NR 1,664 520 4.01 63
0.4 910 184 1.64 NR 1,291 341 2.83 NR 1,608 526 4.03 65
0.5 857 197 1.75 NR 1,237 350 2.90 NR 1,568 532 4.12 67
0.6 809 201 1.83 NR 1,185 362 3.05 NR 1,515 546 4.14 69
0.7 739 207 1.86 NR 1,134 369 3.09 NR 1,477 552 4.18 71
0.8 703 218 1.96 NR 1,087 382 3.21 NR 1,422 562 4.23 74
Unit
Static CFM WATTS AMPS CFM WATTS AMPS
0.1 1,942 649 4.83 2,067 792 5.81
0.2 1,883 657 4.87 2,030 811 5.85
0.3 1,859 670 4.96 1,982 814 5.88
0.4 1,827 675 4.97 1,909 808 5.86
0.5 1,749 683 4.99 1,842 798 5.85
0.6 1,706 693 5.10 1,789 772 5.65
0.7 1,655 703 5.12 1,703 763 5.58
0.8 1,588 705 5.11 1,618 732 5.29
T4 COOLING SPEED T5 COOLING SPEED
T4 COOLING SPEED T5 COOLING SPEED
T4 COOLING SPEED T5 COOLING SPEED
*PG1360140M41A* - Rise Range: 45° - 75°
*PG136090M41A* - Rise Range: 45° - 75°
T1 HEATING SPEED T2 HEATING SPEED T3 HEATING SPEED
T3 HEATING SPEED
*PG1360115M41A* - Rise Range: 45° - 75°
T2 HEATING SPEED
T2 HEATING SPEED T1 HEATING SPEED
T1 HEATING SPEED
T3 HEATING SPEED
