8. KEYBOARD AND DISPLAY
GEK-106168E DBF Breaker Failure Protection 45
If the setting entered is outside the limits of the valid range, the relay will not accept the change and will show the
following message:
Some settings do not accepts numeric values; instead of that, different possibilities will be shown by pressing
left/right arrow keys.
To perform MODIFY OF PROTECTION COUNTERS, the available menus are:
Level 1 Level 2 Level 3 Valid Range
I2t A COUNTER 0-999999
I2t B COUNTER 0-999999
I2t C COUNTER 0-999999
Nº A OPENINGS 0-9999999
Nº B OPENINGS 0-9999999
MO
DIFY
COUNTERS
PRO
T
ECT
IO
N
Nº C OPENINGS 0-9999999
SETTING OUT
OF RANGE
