multi-mode ST.
When connecting fiber media to ST connectors, simply twist on the two round male
connectors into the ST female jacks of the Fiber connector until it clicks and secures.
3.2.4 Connecting
Single-Mode Fiber Optic
When using single-mode fiber cable, be sure to use single-mode fiber port connectors.
Single-mode fiber cable has a smaller diameter than multi-mode fiber cable (9/125 microns for
single-mode, 50/125 or 62.5/125 microns for multi-mode where xx/xx are the diameters of the
core and the core plus the cladding respectively). Single-mode fiber allows full bandwidth at
longer distances, about 20Km with the single-mode SC.
The same procedures as for multi-mode fiber apply to single-mode fiber connectors.
Follow the steps listed in Section 3.2.2 above.
3.2.5
Power Budget Calculations for P62-Series Fiber Media
Receiver Sensitivity and Transmitter Power are the parameters necessary to compute
the power budget. To calculate the power budget of different fiber media installations using
Magnum products, the following equations should be used:
OPB (Optical Power Budget) = P
T
(min) - P
R
(min)
where P
T
= Transmitter Output Power, and P
R
= Receiver Sensitivity
Worst case OPB = OPB - 1dB(for LED aging) - 1dB(for insertion loss)
Worst case distance = {Worst case OPB, in dB} / [Cable Loss, in dB/Km]
where the “Cable Loss” for 62.5/125 and 50/125
μm
(m.m.) is 2.8 dB/km,
and the “Cable Loss” for 100/140 (Multi-mode) is 3.3 dB/km,
and the “Cable Loss” for 9/125 (Single-mode) is 0.5 dB/km
The following data has been collected from component manufacturer’s (HP’s and Siemens’) web
sites and catalogs to provide guidance to network designers and installers.
Fiber
Port
Module
Speed,
Std.
Mode
Std. km
fdx
(hdx)
Wave-
length
nm
Cable
Size
μm
X’mitr
Output
P
T ,
dB
R’cvr
Sens.
P
R ,
dB
Worst
OPB,
dB
Worst*
distance
Km, fdx
typical
OPB,
dB
typical*
distance
Km, fdx
P62-
xMSC
100Mb
FX
Multi-
mode
2
(0.4)
1300
62.5/125
50/125
-20
-23.5
-31
-31
9.0
5.5
2.5
2.0
14
12
5
4
P62-
xSSC
100Mb
FX
Single-
mode
20
(0.4)
1300
9/125 -15 -31 14 28
17.5 35
“Long
Reach”
100Mb
FX
Single-
mode
40
(0.4)
1300
9/125 -5 -34 27 54 32.5 65
