Gold's Gym GGSY2921.0 - Manual (Page 5)

5
M10 Nylon Locknut (72)
M8 Nylon Locknut (71, 105)
M8 x 70mm Carriage Bolt (76)
M
10
x
21
5m
m
Bo
lt
(8
1)
M10 x 25mm Button Screw (83)
M8 x 25mm Button Screw (74)
M4 x 16mm Screw (86)
M8 x 38mm Carriage Bolt (75)
M4 x 25mm Screw (85)
M8 Split Washer (104)
M10 x 83mm Bolt (92)
M10 x 69mm Bolt (91)
M6 x 16mm Screw (67)
M6 Washer (69)
M10 x 60mm Button Bolt (89)
M4 x 12mm
Screw (102)
M
M10 Split Washer (70)
M8 x 25mm Patch Screw (25)
M6 x 38mm Screw (90)
M10 x 107mm Bolt (88)
M8 x 64mm Bolt (101)
PART IDENTIFICATION CHART
Refer to the drawings below to identify small parts used in assembly. The number in paren-
theses by each drawing is the key number of the part, from the PART LIST in the center of
this manual. Note: Some small parts may have been pre-attached. If a part is not in the
parts bag, check to see if it has been pre-attached.
