Grandstream Networks, Inc. BT-200 User Manual Page 18 of 35
Firmware 1.1.1.14 Last Updated: 12/2006
Menu Item Menu Functions
10
Display “[10] Phy Addr”
Press MENU to display the physical / MAC address.
Press ‘↓’ or ’↑’ to exit.
11
Display “[11] ring 0”
Press MENU to hear the selected ring tone, press ‘↓’ or ’↑’ to select the stored ring
tones. There are 3 available ring-tones: ring 0 (default), ring 1 and ring 2. ring 3 is
unavailable or unsupported.
Press MENU to select and exit.
Factory
Reset
Display “ -- rESEt --”. Please be very careful when using this function.
Two options: factory reset or manual reboot.
Factory Reset:
1. Key in the physical / MAC address on back of the phone.
2. Press MENU to reset phone to FACTORY DEFAULT settings. All your
setting will be erased.
Manual Reboot: Press MENU without keying anything.
Others
When phone is powered on and time is displayed
Press ‘↓’ or ’↑’, Display “ ring [4] ”, press ‘↓’ or ’↑’ again to hear and adjust the ring
tone volume, from 0 (off) to 7 (maximum), off and on hook to set
Press SPEAKERPHONE button, or off hook and pick up handset, press ‘↓’ or ’↑’ to
adjust the speakerphone/headset or handset volume.
C ONFIGURATION WITH W EB B ROWSER
The BT–200 has an embedded Web server that will respond to HTTP GET/POST requests. It also has
embedded HTML pages that allow a user to configure the IP phone through any web browser.
Access the Web Configuration Menu
The IP Phone Web Configuration Menu can be accessed by the following URI: http://Phone-IP-Address
where the Phone-IP-Address is the IP address of the phone. To find your IP address, press MENU and
select the Status item to see “IP: IP Address”.
NOTE: When typing the IP address into a browser, strip out the leading “0” as the browser will parse in
octet. e.g. if the IP address is: 192.168.001.014, please type in: 192.168.1.14.
E
ND
U
SER
C
ONFIGURATION
Once this HTTP request is sent from a Web browser, the web server will display a login screen. The
password is case sensitive with maximum length of 25 characters. The factory default password for the
End User is “123”. After login, the embedded Web server will display the Configuration page, explained
in detail in Table 8.
