GA-EP45-UD3LR/UD3L Motherboard
- 56 -
2-9
PC Health Status
Reset Case Open Status
Keeps or clears the record of previous chassis intrusion status. Enabled clears the record of
previous chassis intrusion status and the Case Opened field will show "No" at next boot. (Default:
Disabled)
Case Opened
Displays the detection status of the chassis intrusion detection device attached to the motherboard
CI header. If the system chassis cover is removed, this field will show "Yes", otherwise it will
show "No". To clear the chassis intrusion status record, set Reset Case Open Status to Enabled,
save the settings to CMOS, and then restart your system.
Current Voltage(V) Vcore/DDR18V/+3.3V/+12V
Displays the current system voltages.
Current System/CPU Temperature
Displays current system/CPU temperature.
Current CPU/SYSTEM/POWER FAN Speed (RPM)
Displays current CPU/system/power fan speed.
CPU Warning Temperature
Sets the warning threshold for CPU temperature. When CPU temperature exceeds the threshold,
BIOS will emit warning sound. Options are: Disabled (default), 60
o
C/140
o
F, 70
o
C/158
o
F, 80
o
C/176
o
F,
90
o
C/194
o
F.
CPU/SYSTEM/POWER FAN Fail Warning
Allows the system to emit warning sound if the CPU/system/power fan is not connected or fails.
Check the fan condition or fan connection when this occurs. (Default: Disabled)
CMOS Setup Utility-Copyright (C) 1984-2008 Award Software
PC Health Status
Reset Case Open Status
[Disabled]
Case Opened
No
Vcore
1.316V
DDR18V
1.808V
+3.3V
3.264V
+12V
12.105V
Current System Temperature
43
o
C
Current CPU Temperature
28
o
C
Current CPU FAN Speed
2518 RPM
Current SYSTEM FAN2 Speed
0 RPM
Current POWER FAN Speed
0 RPM
Current SYSTEM FAN1 Speed
0 RPM
CPU Warning Temperature
[Disabled]
CPU FAN Fail Warning
[Disabled]
SYSTEM FAN2 Fail Warning
[Disabled]
POWER FAN Fail Warning
[Disabled]
SYSTEM FAN1 Fail Warning
[Disabled]
CPU Smart FAN Control
[Auto]
CPU Smart FAN Mode
[PWM]
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
